Maintenance

USER-MAINTENANCE INSTRUCTIONS

CARE OF YOUR CLIPPERS

Maintenance of the blade

Always apply oil to the blades before, during and after use. This will ensure maximum

cut

ting performance. Hold clipper away from your body in a downward position and

apply oil on the front and sides of the cutter blade. Wipe excess oil off with a soft,

dry cloth.

Our hair clippers are carefully inspected to ensure that the blades are in perfect

alignment. You will need to realign the blades if they should be knocked out of

alignment. How can you tell if the blades need realigning? Simply match them up, point

for point, to conform with the drawing at right.

To replace cutting comb and cutter after removal

for cleaning, replacement or because they are out

of alignment, slide the cutter back onto the black

plastic oscillating head. Next, you must make sure

that the cutter (small blade) and the cutting comb

(large blade) are properly aligned. Line up the new

or existing cutting comb with the two screw holes.

Place the original screws, one in each hole, and lightly

tighten with a Phillips head screwdriver

(see Fig. 3).

Then, match the two blades up, point to point,

conforming with the illustration below in Fig. 4.

* The top edge of the cutting comb should be 1/32" to

1/16" (0.79mm to 1.59mm) higher than the top edge

of the cutter. This is important so that the clipper does

not cut too close or come in contact with the skin.

* The extreme left tooth of the cutting comb must cover or be to the extreme left of the

first small tooth of the cutter.

* Be sure that the extreme right big tooth of the cutter touches the extreme right tooth

of the cutting comb.

Large blade

(cutting comb)

Small blade

(cutter)

Blade screws

Fig. 3

Cutting comb

(large blade)

Fig. 4

Cutter

(small

blade)

1/32" to 1/16"
