TABLE: FLASHING LIGHT AND COURTESY LIGHT WARNING SIGNALS AND ALARMS

TROUBLE-SHOOTING

Carry out all the required connections as shown in the electrical diagram, position the doors in a neutral mid position, and then check that DL3 and DL4 LED lamps are illuminated and working

correctly.

Should the LED lamps fail to come on, leave the doors in a neutral mid position and then check and - if necessary - replace components.

DL3 Off Photocell failure (In the event that the photocells are not connected, create a jumper between terminals 3 and 4).

DL4 Off Safety strip failure (In the event that the safety strip is not connected, create a jumper between terminals 5 and 6).

During dead man’s switch operations, when DIP 8 is set to ON, check that the DL7 LED lamp (green) comes on during opening operations and that the DL6 LED lamp (red) comes on during

closing operations. In the event that actions are inverted, reverse motor wires on J5 connector.

Check that the DL7 LED lamp (green) when the door opening operation stops and that the DL6 LED lamp (red) goes off when the door closing operation stops. If this does not happen, then

invert the wires of LSO and LSC on J9.

TECHNICAL CONTROL PANEL SPECIFICATIONS

Temperature range 0÷55 °C

Humidity <95% without condensation

Mains voltage 230 V~ ±10 % (120 V~ ±10 %

on demand)

Frequency 50/60 Hz

Power supply microinterruption 100 ms

Transformer capacity 130 VA - primary 230 Vac -

secondary 18 Vac

Max. load at flashing light output point 20 W a 24 Vdc with resistive

load

Maximum board absorption (excluding auxiliary units) 45 mA

Available auxiliary unit power supply 0.8 A +/-15% 24 Vdc

RADIO TECHNICAL SPECIFICATIONS

Reception frequency 433.92 MHz

Impedance 52

Sensitivity >2.24μV

Excitation time 300 ms

De-excitation time 300 ms

Available code memory 120 for up-and-over door command;

120 for courtesy light.

Available radio connector current 200 mA 24 Vdc.

- All inputs should be employed as free contacts; power is generated internally on the board and made available in such a way so as to guarantee double or reinforced insulation

for all live parts.

- All inputs are managed by a programmed integrated circuit that self-monitors operations at start-up.

EVENT CAUSE COURTESY LIGHT WARNING SIGNAL FLASHING LIGHT WARNING

SIGNAL

Encoder alarm. Failure, detached wire or manual release

activated.

Constant. 2s ON and 0,4s OFF.

Active for 5 minutes when battery powered.

Light on for 1 minute.

Safety strip alarm Double impact during an operating cycle.

Constant. 0,3s ON and 2s OFF.

Active for 5 minutes when battery powered.

Light on for 1 minute.

Safety strip self test alarm. Failed self test at opening operation closure.

Constant. 0,3s ON and 2s OFF.

Active for 5 minutes when battery powered.

Light permanently on. Active for 5

minutes with battery power.

Alarm signalling limit switch not pressed

down and excess power load both in

opening and closing operations.

Opening or closing limit switches incorrectly

calibrated.

Constant. 0,28s ON and 2s OFF.

Active for 5 minutes when battery powered.

Off.

Power supply sensor alarm. Double impact during an operating cycle.

Constant. 0,3s ON and 2s OFF.

Active for 5 minutes when battery powered.

Light on for 1 minute.

Activated photocell or safety strip alarm. Photocell or strip activated by a command.

0,1s ON and 0,2s OFF, active for 20s.

Off.

Radio code memory full. Memory full.

Flashes 6 times.

Off.

Power supply threshold value resetting. Resetting not required or RUN trimmer

calibration carried out following the first

operating cycle.

3 flashing lights after having pressed down the

K COVER button for 15 seconds.

Off.

FAULT ACTION

All LED lamps are off after having connected the parts

and supplied power.

Check voltage supply to terminals L to N.

Check F1 and F2 fuses for damage. Replace any interrupted fuses with fuses of the same specifications: F1 = 3.5

A F2 = 8A.

The door opens but does not close after the set time. Check that the DL9 LED lamp is on.

K command button is still inserted in automatic mode (DIP 1 OFF). Replace the button or selector switch.

Safety strip self test failure => check the control panel-safety strip power supply connection.

Warning: If there is no power supply unit for safety strips, DIP 6 should be in an OFF position.

The door does not open or close when the K, K COVER

or RADIO command buttons are activated.

Safety strip contact failure. Photocell contact failure with DIP 2 OFF. Repair or replace the contact in question.

The pedestrian door microswitch is open. Replace, making sure that the DL3 LED lamp is on.

The door reverses the required movement without the

presence of any obstruction.

Carry out power supply threshold resetting procedure as described in the section POWER SUPPLY SENSOR

SENSITIVITY RESETTING PROCEDURE.

The motor starts but the door remains stationary; the

motor stops after 40 seconds and the courtesy light

starts flashing.

Reconnect the manual release device and activate command function.

When reaching the complete open or close position, the

garage door reverses the movement.

Carry out the electrical limit switch adjustment.

The manual release operation is rather noisy. Carry out a fine adjustement of the electrical limit switches.
