2. Description
The audio and audio/video module is equipped with:
- interfacing to acoustic devices used by the hard-of-hearing;
- voice synthesis, for signalling the call state;
- full-duplex audio with Larsen eect removal;
- Front LEDs, for signalling the call state;
- automatic gain control (AGC), to stabilise the speaker output level, whatever the type of system;
- AGC on the microphone level, used to compensate the distance between the outdoor unit used and the tone of voice used in
the communication
- noise suppression, used to eliminate the background noise in the environment surrounding the outdoor unit
- automatic conguration of indoor and outdoor unit addresses.
- dusk/dawn function for automatically adjusting the brightness according to the ambient light.
- zoom & scan function, used to zoom in and scan the areas shown by the video camera (only 40405);
- electric lock control, connected directly to the terminals S+ and S- or to the contacts supported by the keyboard relays;
- connection for an additional local push button to open the lock or for a “Door open” signalling sensor, to the CA+ and CA- ter
-
minals (congurable via SaveProg);
- input for optional local additional power supply (with power supply 6923);
The audio 41002UP module is equipped with an optional video input for an analogue video camera.
The display module provides call functions from the contacts list, extension numbers and to switchboard.
The device provides visual feedback on the operating phases of the outdoor unit, such as the indications for "call in progress" and
"talking", in addition to that associated with the access control modules.
The display module is equipped with an installation menu with which the basic outdoor unit conguration parameters can be
managed.
2.1 Teleloop and control voice synthesis function
The device allows persons with disabilities to listen to the call
audio and receive call status signals via an appropriate hearing
aid.
Enable the hearing aid, referring to its instruction manual.
Control voice synthesis can be disabled with SaveProg.
30/40cm
30/40cm
2.2 Zoom & scan function (only 40405)
This function lets you zoom and scroll through the areas framed
by the cam, as shown in the following gure, with the push but-
tons of an indoor unit.
Please refer to SaveProg for the remaining details.
3
EN
PIXEL UP: 40405 - 40425
