Viale Vicenza 14

36063 Marostica VI - Italy

www.vimar.com

03985 01 2505

EXAMPLE OF USE

The head should be configured as independent and it does not require the creation of a group in the View Wireless App

*The head is inserted in the Bluetooth mesh network and therefore needs at least one mains powered IoT device (control, etc.) to be within its radio range.

1. Climate control zone management from head

2. Climate control from thermostat associated with head

LIVING ROOM

Gateway*

The ZONE 1 head should be configured as “Associated with thermostat”.

The ZONE 2 head should be configured as independent.

This type of application can only be “Winter” and is configured in the View Wireless App by creating the Climate Control group  Remote actuators and Heads  Winter  Relay

ZONE 1 ZONE 2

Gateway

3. Climate control from thermostat associated with two heads and one relay for “zone consent”

Configure the heads as “Associated with thermostat”.

This type of application can only be “Winter” and use one of either art. 03981, 03983 or 03985 to control the valves.

In the View Wireless App, create the Climate Control group  Remote actuators and Heads  Winter  Relay

03981

IoT SWITCH

ACTUATOR

100-240V~ 50/60Hz

500W 240V~

250W 100V~

MADE IN ITALY

L 1

LIVING AREA

Art. 03981 or 03983 or 03985

Gateway
