EN-20
Viking | RVL Panorama Cooktop & Downdraft
MVIDC6364B/6485B
26
Carefully place the downdraft glass cap (Part-C) with the
pins in the cut-outs provided in the downdraft�
Perform the above action carefully to prevent glass
damage and scratches.
27
=
=
=
Surface mounting: Adjust the position of the induction
cooktop until the spacing around the tower top glass and
cut-out is even�
Flush mounting: Adjust the position (front, back, left and
right) of the cooker downdraft until the spacing around
the downdraft tower glass cap and the cut-out is even�
(STEP
18
,
21
)
Secure Cooktop to Downdraft
28
Secure the position of the cooktop on the downdraft with
the Part-M screws (4x for 36”)� Tighten these bolts only
finger tight, do not use a hand-held screwdriver�
