18
USA
10 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL
CONNECTIONS
10.1 DRAIN HOSE CONNECTION
Connect the drain hose to the drain plumbing.
1. Use the supplied rubber connection hose and drain hose clamps to connect the
dishwasher drain hose to the plumbing drain connection.
2. Use the spring clamp to secure the rubber connection hose to the dishwasher drain
hose. Use the screw clamp to secure the rubber connection hose to the plumbing drain
connection.
10.2 DRAIN PREPARATION
The dishwasher drain hose may be connected to the drain plumbing in one of three ways
(Figure A, B, C).
NOTICE :
• Either one of the methods below must be used or the dishwasher will not operate
properly.
• A hose that attaches to a sink spray can burst if it is installed on the same water line as
the dishwasher. If your sink has one, it is recommended that the hose be disconnected
and the hole plugged.
• The total length of the drain hose is 7' (1950mm). If a hose extension is required, a
drainage hose of equal quality must be used.
• The maximum length must not exceed 157 ½” (4000mm). Otherwise, the cleaning
process is negatively influenced.
