Handleiding
Je bekijkt pagina 12 van 47
3,50
Refrigerator-Fr
GREENWOOD,
MISSISSIPPI 38930
VIKING
RANGE, LLC
MODEL/MODELE
NUMBER/NUMERO
SERIAL/SERI
E
NUMBER/NUMERO
REFRIGERANT
TYPE
BLOWING
AGENT
TOTAL
GROSS VOLUME (L)
FREEZING
CAPACITY
REFRIGERANT
CHARGE
(oz) (gms)
VKFDBMIC7360RA
2525001050001
HFO-1336mzz(Z)
(60,00)
(48,00)
575
CLIMATE CLASS
REFRIGERANT TOTAL MASS
(REFRIGERATOR/FREEZER)
MAX. RATED CURRENT (A)
CURRENT COOLING SYSTEM
ICE MAKER ELEMENT WATTS
DEFROST SYSTEM WATTS
VOLTS/FREQUENCY
LISTED HOUSEHOLD REFRIGERATOR
R600a
213
115/60
FF
FZ
1,70 2,10
(0,23 lbs (108 gms))
WATER SUPPLY IN Mpa (bars),Min 0.15 (1.5)-Max 1
12
3. BEFORE STARTING
3.1. Getting started
Congratulations on purchasing your new Viking re-
frigerator! From now on you can use our innovative
storage system, which will allow you to store all of
your food in the best possible way. This manual will
answer most of your questions about the product’s
features.
3.2. Manufacturer’s liability
Viking declines all liability for damage to persons or
property caused by:
> uses of the appliance other than those specified;
> failure to comply with the instructions in the user
manual;
> tampering with any part of the appliance;
> use of non-original spare parts.
3.3. Technical support
> In the event of appliance failure, contact techni-
cal support and have the repair carried out by quali-
fied personnel only.
> Make sure you have the model and serial num-
ber on hand (located on the identification plate).
> Use only original spare parts.
> Do not try to repair the appliance yourself or with-
out the assistance of a qualified technician; this has
safety repercussions and may void the warranty.
> Detailed information on the duration of the war-
ranty and the warranty conditions in each country
can be found from Viking Customer Support, your
dealer or on our website.
> If you need further information, do not hesitate to
contact the Technical Assistance Centre:
Viking Range, LLC
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information, call 1-888-(845-4641)
or visit the our web site at vikingrange.com
Important
Before calling, make a note of the appli-
ance’s serial number located inside the
refrigerator compartment on the side op-
posite the door opening.
3.4. Product plate
The product plate shows the technical data, the se-
rial number and the model. The product plate must
never be removed or damaged.
Conservation Tips
> SN (Subnormal) from +50°F to +90°F (+10° to +32°C).
> N (Normal) from +61°F to +90°F (+16° to +32°C.
> ST (Subtropical) from +64°F to +100°F (+18°C to +38°C).
> T (Subtropical) from +64°F to +109°F (+18°C to +43°C).
The product plate is
positioned
on the side opposite
door opening.
Refrigerator
+46/+35°F
(+7°C/+1°C)
Fresh Select
5°F/-8°F
(-13°C/-23°C)
