4. Operation Controls and Functions
4.1 Front Panel
No.
Name
Function Description
1
USB 3.0 ports
USB 3.2 Gen 1 device ports, connected to USB 3.0 flash disk,
camera, printer etc.
2
USB 3.0 ports
(with hotkey
mode)
▪ When Hotkey switch to OFF mode, these two ports support
USB 3.2 Gen 1 device.
▪ When Hotkey switch to ON mode, these two ports support
USB 1.1 mouse and keyboard only.
3
Power LED
The Power LED will light in green when the product is working,
and red when the product is on standby.
4
Input channel
LED 1/2
When the HDMI input port 1/2 is selected as the signal input
channel, the corresponding LED 1/2 will light in green.
5
AUTO LED
When the auto switching function is enabled, the AUTO LED
will light in green, otherwise it will light off.
6
IR Window
IR signal receiving window.
7
HOTKEY
switch
Use the switch to enable/disable the hotkey switching mode.
▪ Switch to “ON”: The connected keyboard and mouse support
hotkey switching mode.
▪ Switch to “OFF”: The connected keyboard and mouse don’t
support hotkey switching mode.
8
SELECT
button
Press the button to switch the input channel.
