9 / 11
10.
ASCII Commands
The product also supports ASCII commands control. Connect the RS-232 port
of the product to a PC with a 3-pin phoenix connector cable and an RS-232 to
USB cable. The connection method is as follows.
TX
Ground
RX
3-pin Phoenix Connector
PC
RS-232
RS-232 to USB cable
Then, open a Serial Command tool on PC to send ASCII commands to
control the product.
The ASCII commands list about the product is shown as below.
ASCII Commands
Serial port protocol. Baud rate: 115200 (default),
Data bits: 8, Stop bits:1, Check bit: 0
x - Parameter 1 z - Parameter 2 ! - Delimiter
Command Code
Function Description
Example
Feedback
Default Setting
help!
List all commands
help!
status!
Get device current status
status!
r type! Get device model
r type!
2x1 dual monitor kvm
hdmi2.0 switcher
r fw version!
Get firmware version
r fw version!
mcu fw version:
vx.xx.xx
kvm fw version:
vx.xx.xx
power z!
Power on/off the device
(z=0~1)
0. power off
1. power on
power 1!
power on
r power!
Get current power state
r power!
power on
reboot!
Reboot the device
reboot!
reboot…
