5/12
5. Operation Controls and Functions
5.1 Front Panel
No.
Name
Function Description
1 RESET Button
USB 3.2 Gen 1 device ports, connected to USB 3.0 flash
disk, camera, printer etc.
2
USB 3.0 ports
(with hotkey
mode)
▪
When Hotkey switch to OFF mode, these two ports
support USB 3.2 Gen 1 device.
▪
When Hotkey switch to ON mode, these two ports
support USB 1.1 mouse and keyboard only
3 Power LED
The Power LED will light in green when the product is
working, and red when the product is on standby.
4
Input channel
LED 1/2
When the HDMI input port 1/2 is selected as the signal input
channel, the corresponding LED 1/2 will light in green.
5 AUTO LED
When the auto switching function is enabled, the AUTO
LED will light in green, otherwise it will light off.
6 IR Window
IR signal receiving window.
7
HOTKEY
switch
Use the switch to enable/disable the hotkey switching
mode.
▪ Switch to “ON”: The connected keyboard and mouse
support hotkey switching mode.
▪ Switch to “OFF”: The connected keyboard and mouse
don’t support hotkey switching mode.
8
SELECT
button
Press the button to switch the input channel.
