Port Settings
1. IR Voltage: Click the drop-down menu to select the 5V/12V
IR voltage.
2. IO Voltage: Click the drop-down menu to select the 5V/12V
IO voltage.
3. IO 1 Direction: Click the drop-down menu to set the IO 1
direction (Input/ Output).
4. IO 1: Click the drop-down menu to set the IO 1 level (Low/
High).
5. IO 2 Direction: Click the drop-down menu to set the IO 2
direction (Input/ Output).
6. IO 2: Click the drop-down menu to set the IO 2 level (Low/
High).
7. Relay 1: Click the drop-down menu to select Open/Close
Relay 1.
8. Relay 2: Click the drop-down menu to select Open/Close
Relay 2.
Reboot: Click the Reboot button to reboot the Decoder.
Replace: Click to replace the oine Decoder (which is in the
system) with an online Decoder (which is not in the system).
The method to replace Decoders is the same as the Encoder
replacement.
Remove: Click the Remove button to remove the Decoder from
the system.
Remove All: Click this button to remove all Decoders from the
system.
Factory Reset: Click this button to restore the Decoder to
factory settings.
