Connecting for a Smarter Future
6. Rack Mounting Instruction
6.1 6U V2 Rack Mounting
This Controller can be mounted in a standard 6U rack (Please
contact your supplier for 6U rack sale). The mounting steps are
as follows:
Step 1: Use included screws to x two mounting ears on the
Controller, as shown in the gure below:
12
Step 2: Insert the Controller with mounting ears into a 6U
rack (up to 10 units can be installed vertically), as shown in the
gure below:
