- 2 / 37 -
Package Contents
① 1 x Digital Audio Processor
② 1 x AC 100~240V 50/60Hz Power Cord
③ 1 x 3pin-3.81mm Phoenix Connectors (Male)
④ 1 x 10pin-3.81mm Phoenix Connectors (Male)
⑤ 4 x 12pin-3.81mm Phoenix Connectors (Male)
⑥ 2 x Mounting Ears (Wall Mount)
⑦ 8 x Machine Screws (KM3*4)
⑧ 1 x User Manual
3. Specifications
Technical
Amplitude-frequency
(20Hz~20KHZ@+4dBu)
±0.2dB
THD+N (1KHZ@+4dBu)
≤ 0.01%
SNR (linear input)
≥ 90dB
Dynamic Range
≥ 100dB
Channel Level Difference
±0.5dB
Channel Isolation
≥ 80dB
Max Input Level
20dBu
Max MIC Gain
40dB
Input Impedence
20KΩ
Output Impedence
300Ω
Sampling Frequency
48KHZ
A/D and D/A Conversion
24Bit
Phantom Power
+48 VDC
Connection
Inputs
8 × Balanced MIC/LINE [3-pin phoenix connector] or
4 × Stereo Audio [3-pin phoenix connector]
Outputs
8 × Balanced LINE [3-pin phoenix connector] or
4 × Stereo audio [3-pin phoenix connector]
Controls
1 × LAN [RJ45]
1 × RS-232 [3-pin phoenix connector]
8 × GIPO [10-pin phoenix connector]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
440mm (W)×250mm (D)×45mm (H)
Weight
3.3kg
Power Supply
AC 100 - 240V 50/60Hz
Power Consumption
9W (Max)
Operating Temperature
0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature
-20°C ~ 60°C / -4°F ~ 140°F
Relative Humidity
20~90% RH (non-condensing)
