19User Manual Visit the ViewZ USA website at https://www.viewzusa.com
CONTROL AND FUNCTION
2P PIP (INPUT MODE)
INPUT
DISPLAY FUNCTION
SELECT REGION
2P PIP POSITION
2P PIP MAIN INPUT
2P PIP SUB INPUT
2P PIP SIZE
2P PIP SWAP
ENTER 2PLR MODE
AUDIO INPUT
Select the video source input for dual display.
Select the main, sub or both areas to adjust the
monitor setup ( Region Adjust & SET values).
Set up the PIP position.
Select the main input source.
Select the sub input source.
Set up the PIP size. 10 is 25% and 0 is 5%.
Swap PIP's main and sub picture.
Select a display type among 1P, 2PLR, 2PTB, 2P PIP & 4P,
if current display mode is not '2P PIP'.
Select an audio Input source among two input source.
D0 DP / D1 HDMI / D2 HDMI
D0 DP / D1 HDMI / D2 HDMI
2PPIP FULL / 2PIP MAIN /
MID/USER/LEFT TOP/RIGHT TOP
LEFT LOW / RIGHT LOW
2PIP SUB
0 ~ 10
-
-
2P PIP MAIN INPUT /
2P PIP SUB INPUT
D3 HDMI / D4 HDMI / AUTO
D3 HDMI / D4 HDMI
FUNCTION VALUE
