- 3G-SDI Input *2
8) SDI Output
- 12G-SDI Output *2
- 3G-SDI Output *2
9) GPI Input (RJ45, 8-pin): See Page22 GPI 1-8.
10) RS422 Input (RJ45, 8-pin): Supporting the default and TSL V3.1 protocols to control Monitor.
Follow this instructions about this port.
PIN Number Instruction
PIN 1 Y
PIN 2 Z
PIN 3 A
PIN 4 NC
PIN 5 NC
PIN 6 B
PIN 7 NC
PIN 8 GND
11) RS422 Output (RJ45, 8-pin): Supporting the default and TSL V3.1 protocols to control Monitor. The
instructions about the port is as above.
12) LAN (10/ 100) Input (RJ45): Supporting the default protocol to control Monitor.
Note: The "RemoteTerminal.exe" as default protocol to control Monitor.
