Handleiding
Je bekijkt pagina 23 van 28
17’’
19’’
LCD-Type
17˝ Diagonal AM-TFT(Active-Matrix)
19˝ Diagonal AM-TFT(Active-Matrix)
Pixel pitch(mm) : 0.264(H) x 0.264(V)
Pixel pitch(mm) : 0.294(H) x 0.294(V)
BRIGHTNESS: 250cd/㎡(Typical)
BRIGHTNESS: 250cd/㎡(Typical)
CONTRAST RATIO: 1000:1(Typical)
CONTRAST RATIO: 800:1(Typical)
RESPONSE TIME: 5msec(Typical)
RESPONSE TIME: 5msec(Typical)
RESOLUTION (H x V)
1280X1024 @60Hz
FREQUENCY
HORIZONTAL: 31~64KHz
VERTICAL: 50~75Hz
INPUT SIGNAL
VIDEO(2ch input 1.0Vp-p, 75Ω terminated, loop-through out)
SYNC(Separate TTL Level)
AV(composite) Sound in
PC Stereo Sound
ACTIVE DISPLAY AREA
(W x H)
337.9 mm X 270.3 mm
376.32mm X 301mm
PACKING DIMENSIONS
(W x D x H)
435mm X 235mm X 472mm
(17.13’’ X 9.25’’ X 18.58’’)
495mm X 235mm X 505mm
(19.49’’ X 9.25’’ X 19.88’’)
WEIGHT
Net Weight : 5.18Kg (11.4 lbs)
Net Weight : 5.47Kg (12.03 lbs)
Gross Weight : 6.98Kg (15.36 lbs)
Gross Weight : 7.47Kg (16.43 lbs)
ELECTRICAL RATINGS
DC 12V / 3A
DC 12V / 3.5A
▶▶ NOTE :
Technical specifications are subject to change without notice.
INSTRUCTION MANUAL ……………………………………………………………………. 21
