18 User ManualVisit the ViewZ USA website at https://www.viewzusa.com
MOUNTING GUIDE
Wall Mounting (Optional)
VZ-LX monitors are suitable for VESA wall mount (not included).
1. VZ-24LX, VZ-27LX : VESA WALL MOUNT 75mm x 75mm, 100mm x 100mm
2. VZ-32LX : VESA WALL MOUNT 200mm x 200mm
3. VZ-42LX : VESA WALL MOUNT 300mm x 300mm
Aenon!
VZ-24LX, VZ-27LX : You must use 4 * M4 x L10 screws to assemble this monitor and the wall mount bracket.
VZ-32LX : You must use 4 * M6 x L8 screws to assemble this monitor and the wall mount bracket.
VZ-42LX : You must use 4 * M8 x L8 screws to assemble this monitor and the wall mount bracket.
Mounng Safety !
At least two people are recommended to safely install the mount.
WARNING !
If user uses screws longer than
M4 x L10 mm for VZ-24LX, VZ-27LX,
M6 x L8 mm for VZ-32LX,
M8 x L8 mm for VZ-42LX,
it may cause damage to the unit. Please use bolt of correct size and length as instructed.
M4 x L10 screws for VZ-24LX , VZ-27LX
M6 x L8 screws for VZ-32LX
M8 x L8 screws for VZ-42LX
