166
LAN Hardware Specicaon
ViewSonic LFD communicaon port on the rear side:
1. Connector type: 8P8C RJ45
2. Pin Assignment:
Pin # Signal Remark
1 TX+ Output from Display
2 TX- Output from Display
3 RX+ Input to Display
4 BI_D3+ For 1G case
5 BI_D3- For 1G case
6 RX- Input to Display
7 BI_D4+ For 1G case
8 BI_D4- For 1G case
frame GND
RS-232 Communicaon Seng
• Baud Rate Select: 9600bps (xed)
• Data bits: 8 bits (xed)
• Parity: None (xed)
• Stop Bits: 1 (xed)
LAN Communicaon Seng
Type: Ethernet
Protocol: TCP/IP
Port: 5000 (xed)
WOL Port: 9 (xed) for UDP
*3.2.0
Cross subnet: No
Logon Credenals: No
Command Message Reference
PC sends to LFD command packet followed by “CR”. Every me PC sends control
command to Display, the Display shall respond as follows:
1. If the message is received correctly it will send “+” (02Bh) followed by “CR”
(00Dh)
2. If the message is received incorrectly it will send “-” (02Dh) followed by “CR”
(00Dh)
