RS-232 Protocol
This document describes the hardware interface and soware protocols of RS-232
interface communicaon between the ViewSonic LED Display and computers or
other control units with RS-232 protocol.
Descripon
RS-232 Hardware Specicaon
ViewSonic RS-232 serial port on the lower le side:
1. Connector type: DB 9-Pin Female.
2. Use of straight-through parallel cable for connecon
3. Pin Assignment:
Female DB 9-Pin
Pin # Signal Remark
1 NC
2 RXD Input to Display
3 TXD Output from Display
4 NC
5 GND GND
6 NC
7 NC
8 NC
9 NC
frame GND
RS-232 Communicaon Seng
• Baud Rate Select: 115200bps (xed)
• Data bits: 8 bits (xed)
• Parity: None (xed)
• Stop Bits: 1 (xed)
NOTE: Make sure the Control Board Switch is switched to the le for RS-232
control.
