Instructions manual - English - EN
7MNVKUPTPSUL_2222_EN
6.1.6 Sheath assembly
The operation is only to be carried out with
UL certied versions.
Straight cut of conduit.
Fig. 11
Push the silicone sheath completely into the
connector.
Fig. 12
To re-open use a screwdriver.
Fig. 13
7 Configuration
The product has already been set in the factory for
optimal operation under a range of conditions. The
product features can be suited to the operating
situation.
Use trimmer P1 to adjust the intervention threshold
of the twilight sensor. (6.1.2 Board description, page
4).
By rotating the trimmer clockwise, the night mode
changeover is anticipated (at a greater luminous
value). By rotating the trimmer anti-clockwise,
the night mode changeover is delayed (at a lower
luminous value).
We recommend making the adjustments under the
actual conditions in which the spots will be used.
The switching on of the red LED on the board stands
for the activation of the night-time mode.
