Pag. 3 MNVCNXPTH_1511_EN
Identification data
On NXPTH pan & tilt motors there are two plates complying with EC specifications.
The first plate includes:
Model identification code (Extended bar code 3/9 )
Mains voltage (Volt)
Frequency (Hertz)
Power consumption (Watt)
The second plate shows the model serial number (Extended bar code 3/9)
When installing the appliance, check that the power supply specifications of the pan & tilt motor correspond to those
required. The use of improper appliances may seriously compromise the safety of the personnel and the installation.
Description of NXPTH pan & tilt motors
NXPTH unit is a vertical and horizontal pan & tilt motor, expressly projected for outdoor installations; both
models are equipped with the Preset function.
Features
Horizontal movement (Pan): from 0 to 350°. Speed: 5° per second
Vertical movement (Tilt): from 0 to 355°. Speed: 2,8° per second
Construction in Aisi 316 stainless steel
Completely sealed closing for indoor/outdoor operation
Operating temperature from -20°C to +55°C (from -4°F to 131°F)
PRESET for both models
Appliances compatible with NXPTH
The working of pan & Tilt motors is guaranteed only if connected to:
DTRX3 receiver driver: 17-function digital receiver, allowing the remote control of pan & tilt motors, wiper and
wash, and 4 auxiliary contacts. It can be individually addressed up to 999 units. It allows the management of max.
14 preset positions, which are recalled in the switching cycle by the patrol function.
DTMRX2/DTMRX224 minireceiver driver: 12-function digital receiver, allowing the control of pan & tilt motors
(horizontal and vertical, zoom lenses, autopan). It can be individually addressed up to 99 units.
Installation
The installation must be carried out only by qualified technical staff.
The following procedures must be carried out with power supply off, if not otherwise specified.
Unpacking
If the packing shows no relevant defects (due to falls or anomalous abrasions), check the material contained,
according to the list given at paragraph Packing contents chapter Introduction.
The packing materials can be completely recycled. The installer technician is required to dispose of them according to
the differentiated collecting modalities or ,anyway, according to the normative laws in force in the Country of use.
Check of identification data
Before installing the appliance, check that the material supplied corresponds to the specifications indicated on
the data plate, following the chapter Identification data. Do not carry out any modification or connections which are not
provided for in this manual: the use of improper appliances may seriously compromise the safety of the personnel and
the installation.
