EN - English - Instruction manual
12 MNVCHOV32_2222_EN
11 Technical data
11.1 General
Constructed from aluminium
Sunshield in ABS
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws
11.2 Mechanical
Internal usable dimensions (WxH): 100x70mm
(3.9x2.7in)
Internal usable length (with or without accessories):
250mm (9.8in)
Cable glands: 3xM16
Extra clear glass window
• Dimensions (WxH): 118x75mm (4.6x2.95in)
Unit weight: 3kg (6.6lb)
11.3 Electrical
Supply voltage/Current consumption (empty
version):
• From 12Vdc up to 24Vdc, 1A max
• From 12Vac up to 24Vac, 1A max, 50/60Hz
• From 120Vac up to 230Vac, 400mA max, 50/60Hz
Supply voltage/Current consumption (version with
heater, Ton 15°C±3°C (59°F ±5°F), Toff 22°C±3°C
(72°F±5°F)):
• From 12Vdc up to 24Vdc, 3A max
• From 12Vac up to 24Vac, 3A max, 50/60Hz
• From 120Vac up to 230Vac, 400mA max, 50/60Hz
Supply voltage/Current consumption (version with
heater fan assistant, continuous duty):
• 12Vdc, 400mA max
• 24Vac, 200mA max, 50/60Hz
Supply voltage/Current consumption (version with
wide-range power supply):
• From 100Vac up to 240Vac, 40mA max, 50/60Hz
Supply voltage/Current consumption (version with
blower and thermostat for models with double
filter for air renewal, Ton 35°C±3°C (95°F±5°F), Toff
20°C±3°C (71°F±5°F)):
• 12Vdc, 400mA max
• 24Vac, 200mA max, 50/60Hz
• 120Vac, 0.37A max, 50/60Hz
• 230Vac, 0.19A max, 50/60Hz
Supply voltage/Current consumption (version with
integrated wiper):
• 24Vac, 1.85A max, 50/60Hz
• 230Vac, 40mA max, 50/60Hz
Camera power supply:
• IN from 100Vac up to 240Vac, 50/60Hz - OUT
12Vdc, 1.25A
• IN 230Vac, 50Hz - OUT 24Vac, 50Hz, 400mA
11.4 Environment
For indoors and outdoors installation
Operating temperature (with heater): from -20°C
(-4°F) up to +65°C (149°F)
11.5 Certifications
Electrical safety (CE): EN60950-1, IEC60950-1,
EN62368-1, IEC62368-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3, EN55032 Class B, FCC Part. 15 Class B,
ICES-003 Class B (with wiper: EN61000-6-4, EN55032
Class A, FCC Part. 15 Class A, ICES-003 Class A)
Outdoor installation (CE): EN60950-22, IEC 60950-22
IP protection degree (EN60529):
• IP66/IP67 (with cable glands)
• IP66/IP67 (with bracket with internal cable
channel, with sealing rings)
• IP55 (with bracket with internal cable channel)
• IP44 (with double filter for air renewal)
IK protection degree (EN62262):
• IK10: models HOV32K1A084, HOV32K2A084
• IK10 (except for the front glass): for all the other
models
Salty fog resistance: to 1000 hours (ISO9227)
UL certification (except for versions with double filter
for the air exchange, HOV32K1A018, HOV32K2A016,
HOV32K2A017, HOV32K2A147, and the version with
wiper 230Vac, HOV32K1A100): cULus Listed, TYPE 4X
EAC certification
