EN - English - Instruction manual
10 MNVCHGV_2222_EN
6.7 Fastening of the wiper blade
Insert the blade on the wiper shaft.
Fig. 16
Bring the brush to the stand-by position.
Fig. 17
Correct adjustment must enable the
brush to return to the stand-by position
by stopping against the lower body of the
housing.
Fasten using the washer and nut.
Fig. 18
6.7.1 Fastening of the small plate with
nozzle
Fasten the plate (01) with the nozzle already
assembled on the lower body using the two screws
(02) supplied.
02
01
03
Fig. 19
To calibrate the jet, orientate the nozzle
towards the window of the housing.
Tighten the nut (03) to fasten the nozzle in position.
