Instruction manual - English - EN
9MNVCHEG_2222_EN
10 Technical data
10.1 General
Constructed from aluminium
Epoxypolyester powder painting, RAL9002 colour
Stainless steel external screws
10.2 Mechanical
Internal usable dimensions
• Empty version: 134x88mm (5.3x3.4in)
• Version with double or triple heater : 112x88mm
(4.4x3.5in)
Internal usable length (without accessories)
• HEG37: 365mm (14.3in)
• HEG47: 450mm (18in)
Internal usable length (with accessories):
• HEG37: 273mm (10.7in)
• HEG47: 363mm (14in)
Cable glands: 3xM16
Extra clear glass window
• Dimensions (WxH): 94x80mm (3.7x3.1in)
Unit weight
• HEG37: 4.1kg (9lb)
• HEG47: 4.7kg (10.3lb)
10.3 Electrical
Supply voltage/Current consumption (version with
heater, Ton 15°C±3°C (59°F ±5°F), Toff 22°C±3°C
(72°F±5°F)):
• 12Vdc, 1.6A max
• 24Vac, 0.85A max, 50/60Hz
• 120Vac, 0.35A max, 50/60Hz
• 230Vac, 0.18A max, 50/60Hz
Supply voltage/Current consumption (version
with double heater, Ton 15°C±3°C (59°F ±5°F), Toff
22°C±3°C (72°F±5°F)):
• 120Vac, 0.7A max, 50/60Hz
• 230Vac, 0.35A max, 50/60Hz
Supply voltage/Current consumption (version with
triple heater, continuous duty fan , Ton 15°C±3°C
(59°F ±5°F), Toff 22°C±3°C (72°F±5°F)):
• 120Vac, 1A max, 50/60Hz
• 230Vac, 0.52A max, 50/60Hz
Supply voltage/Current consumption (version
with heater, blower and thermostat for models
with double filter for air renewal, Ton 35°C±3°C
(95°F±5°F), Toff 20°C±3°C (71°F±5°F)):
• 24Vac, 1A max, 50/60Hz
• 120Vac, 0.37A max, 50/60Hz
• 230Vac, 0.19A max, 50/60Hz
Camera power supply:
• IN from 100Vac up to 240Vac, 50/60Hz - OUT
12Vdc, 1.25A
• IN 230Vac, 50Hz - OUT 24Vac, 50Hz, 400mA
10.4 Environment
For indoors and outdoors installation
Operating temperature with heating: from -20°C
(-4°F) up to +60°C (140°F)
Operating temperature with double heater: from
-40°C (-40°F) up to +60°C (140°F)
Operating temperature with triple heater: from -50°C
(-58°F) up to +60°C (140°F)
10.5 Certifications
Electrical safety (CE): EN60065, EN62368-1
Electromagnetic compatibility (CE): EN50130-4,
EN61000-6-3
IP protection degree:
• EN60529, IP66/IP67 (with cable glands)
• EN60529, IP44 (with double filter for air renewal)
Salty fog resistance: to 1000 hours (ISO9227)
EAC certification
