Instruction manual - English - EN
9MNVCIRHS_2222_EN
8 Information on disposal
and recycling
The European Directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE) mandates
that these devices should not be disposed of in the
normal flow of municipal solid waste, but they should
be collected separately in order to optimize the
recovery stream and recycling of the materials that
they contain and to reduce the impact on human
health and the environment due to the presence of
potentially hazardous substances.
The symbol of the crossed out bin is marked
on all products to remember this.
The waste may be delivered to appropriate collection
centers, or may be delivered free of charge to the
distributor where you purchased the equipment at
the time of purchase of a new equivalent or without
obligation to a new purchase for equipment with size
smaller than 25cm (9.8in).
For more information on proper disposal of these
devices, you can contact the responsible public
service.
9 Troubleshooting
9.1 Checking the power supply
Check that the unit is supplied with a voltage
between 12-24Vdc or 24Vac +/- 10%.
9.2 Check operation of the
twilight sensor
Check operation of the twilight sensor by darkening
it with black tape.
Leave the telemetry connection open.
10 Technical data
10.1 General
Die cast aluminum body
Supplied complete with horizontal and vertical
rotating support in painted galvanized steel
Wavelengths: 850nm, 940nm, white light
10.2 Mechanical
Dimensions: 133x112x135mm (5.2x4.4x5.3in)
Unit weight: 0.9kg (2lb)
10.3 Electrical
Supply voltage/Current consumption:
• from 12Vdc up to 24Vdc:
1A max (high power 4 LED, 12Vdc), 0.5A max (high
power 4 LED, 24Vdc) or 0.5A max (low power 2
LED, 12Vdc), 0.25A max (low power 2 LED, 24Vdc)
• 24Vac:
0.5A max (high power, 4 LED) or 0.25A max (low
power, 2 LED), 50/60Hz
State of the art SMD LED
Adjustable built-in photocell for automatic activation
and deactivation
Input for activation by means of external dry contact
Supplied with multipole cable: 4x0.34mm² (22AWG),
L=2m
10.4 Illuminators
GEKO IRH BEAM PATTERN AND ACHIEVABLE DISTANCES FOR ONE
ILLUMINATOR
Horizon-
tal and
vertical
beam
patterns
Maximum distance
850nm,
low
power
850nm,
high
power
940nm,
high
power
White
light,
high
power
10˚ 100m
(328ft)
140m
(460ft)
100m
(328ft)
–
30˚ 60m (197ft) 84m (276ft) 60m (197ft) 60m
(197ft)¹
60˚ 40m (131ft) 56m (184ft) 40m (131ft) 40m
(131ft)¹
Tab. 3 The distances and the performance depend on the
camera/lens used and on the environmental light
conditions.
¹ Achievable distances with camera in Day mode
(colour image)
