2. Description and features
2.1. Description
The EV Charging Station NS with its three-phase and single-phase charging capabilities integrates seamlessly into the Victron
environment with its GX device connection via WiFi and enables easy operation and control via Bluetooth and the VictronConnect
App. It delivers a maximum of 22kW AC in three-phase or 7.3kW in single-phase mode.
Not only does this EV charging station fully integrate with a Victron Energy GX device and VRM, if you have solar, it can also be
set up to allow excess energy from the sun to directly charge your vehicle once certain parameters are met. See the EV Charging
Station Setup [14] chapter for details.
The tough plastic enclosure is designed to withstand harsh weather and can be mounted inside or outside. In addition to the
default blue device front, a black and a white front are also available.
A programmable RGB light ring around the charging port (type 2 EV charging plug) allows for quick determination of the device
state and can be programmed from the integrated web interface to display different light effects based on the current state
(disconnected, charging, charged etc.).
2.2. Features
Three operation modes:
1. Automatic mode to ensure maximum PV system efficiency
Thanks to the seamless integration of the EV Charging Station NS with the rest of the Victron installation, it detects when
surplus power is available and uses only this power to charge the vehicle. Note that this mode requires a GX device in
your system and communication between GX device and EVCS enabled. For details, see chapter EV Charging Station
setup [14].
Instead of loosing surplus energy when the batteries are full and, for example, feeding it back into the grid at a lower price, the
energy is stored into the EV battery.
• Seamless integration into the Victron installation
• Detects when excess power is available and uses only that to charge the vehicle before exporting it to the grid
• Ensures maximum PV efficiency
• Battery-powered algorithm (used by default) for automatic mode ensures that automatic mode works even when off-grid
How does it work?
The EVCS will automatically start charging when the vehicle is connected and the following conditions are met:
1. The current state of charge is above the 'Start charging at backup battery SoC (%) value.
2. There is enough excess solar power available, with excess solar power calculated as follows:
• Excess solar power = Total PV production - AC loads (without car consumption) = 1380W (230V x 6A)
In the example above, the Min. charge current (from 6A) value has been set to 6A. The required excess solar power
increases accordingly if a higher value is set for the Min. charge current (from 6A). Please see the chapter EV Charging
Station setup [14] for details on both parameters.
2. Manual mode to configure output current
Manual mode allows configurable output current between 6-32A.
The charging power is controlled in several ways:
• By using the web interface via a web browser
• From a GX device touch screen like the GX Touch 50 & GX Touch 70.
• From the Remote Console
• By using the Controls on the Dashboard of the VRM Portal (requires a GX device)
• Via Bluetooth and the VictronConnect App
It allows charging to be started or stopped manually when an EV is connected to the charging station, regardless of PV
production.
Manual - EV Charging Station NS
Page 2 Description and features
