11. Technical specification
EV Charging Station NS
Input voltage range (V AC) 170 – 265VAC 50Hz
Rated charge current 32A / phase
Nominal power 22kW
Current output range 6 – 32A
Wi-Fi standards 802.11 b/g/n (2.4Ghz only)
Self-consumption 15mA@230V
Configurable Max. Current 10-32A
Configurable Min. Current 6A up to 1A below max. value
Connector type IEC 62196 Type 2
GENERAL
Means to Disconnect Depending on available input power and cable cross-section - max 40A
Configurable price/kWh calculator (EUR) Default setting: 0.13 (adjustable)
Control type Web page, GX device over Modbus TCP, VictronConnect via Bluetooth
Light Ring 55 configurable light effects available
Protection External RCD is required
Operating temperature -25°C to +50°C
Storage temperature -40 °C to +80 °C
Humidity 95%, non-condensing
Data communication ModbusTCP over WiFi, Bluetooth
ENCLOSURE
Enclosure colour Light Blue (RAL 5012), Traffic Black (RAL 9017), Traffic White (RAL 9016)
Power terminals 6-10 mm² / AWG 10-8
Protection category IP44
Ventilation not required
Weight 3 kg
Dimensions (h x w x d) 372 x 292 x 122mm
STANDARDS
Safety IEC 61851-1, IEC 61851-22
Detection for Relay Contact welded
Detection for missing protective conductor
Detection for missing Ground
Detection for shorted CP
Manual - EV Charging Station NS
Page 33 Technical specification
