- 7 -
Pump Wiring
Overheating
This can happen when pump is operated in bypass mode for
no longer than 3 minutes or if low voltage/amps.Ensure that
pump is not left running for longer than 3 minutes without
depressing Transfer Gun trigger.The wiring loom has been
extended using wire of insufficient gauge.25A wire is required
and a matching connector
Pump makes a
squealing/scratching
sound while running
This can be caused by dirt or debris entering the pump and
becoming caught in the working parts.Remove the end cover of
the pump by first unscrewing the three Socket Head screws and
lifting off the cover.Clean the impeller vanes ensuring you remove
any dirt particles caught between the ends of the
vanes and the impeller housing.Do not over-tighten head
screws when reassembling.
Pump stalls when
Transfer Gun trigger is
released,and pump is
running
·The non-return valve in the outlet of the pump may be
jammed shut.Remove the outlet hose from the pump.Operate
the white plastic valve is in the outlet port of the pump manually
(by pushing it in and out),to ensure it moves freely.
To Test &Repair if the
Pumps running but low
or nil flow from nozzle
·Remove gun from hose &re-test,Run the hose into the tank
filling neck while checking
·If flow improves,check hole in the end of the nozzle for blockage
Replace gun as required
Pump runs but does not
pump
Check red alligator clip fitted to positive terminal,black to
negative.If it is the wrong way around the pump runs
backwards
Check that the suction hose and foot filter are immersed in
diesel.The suction hose may be bent up out of the diesel.
·If pump is brand new or has not been used in a long period of
time unscrew automatic gun from hose and put hose in filler neck
to prime pump
