- 9 -
MACHINE
PUMP
MOTOR
DESCRIPTION
Self-priming,volumetric,rotating electric vane pump,equipped with by-pass valve.
Brush motor powered by continuous current,low voltage,with intermittent cycle,
WARNING
MOTOR EQUIPPED WITH AUTOMATIC THERMAL OVERLOAD PROTECTION.
SHOULD THE PROTECTION ACTIVATE,TURN OFF THE PUMP AND WAIT FOR IT
TO COOLDOWN.
DEFINITION OF CLASSIFIED ZONES
FOREWORD
Definition of zones as shown in directive 99/92/EC
ZONE 0
Place where an explosive atmosphere made up of a mix of air and inflammable
substances in the form of gas,vapour or mist is continuously present,either for long
periods or frequently. Note:Generally speaking,said conditions,when they
occur,involve the inside of tanks,pipes and containers,etc
ZONE 1
Place where it is probable that an explosive atmosphere,made up of a mix of air
and inflammable substances in the form of gas,vapour or mist,can occur
occasionally during normal operation
Note: Said zone can also include:
places in the immediate vicinity of zone O;
places in the immediate vicinity of supply openings;
places in the immediate vicinity of filling and and emptying openings;
places in the immediate vicinity of appliances, protection systems and fragile gass
and ceramic components.or components made of other similar materials:
places in the immediate vicinity of inadequately sealed stuffing boxes, e.g, on
pumps and valves with stuffing box.
ZONE 2
Place where it is improbable that an explosive atmosphere,made up of a mix of air
and inflammable substances in the form of gas,vapour or mist,can occur during
normal operation, but which,if it does occurs,only persists for a short time.
Note: Said zone can include, among others, places surrounding the zones O or 1.
ZONE 20
Place where an explosive atmosphere in the form of a cloud of combustible
powders in the air is continuously present, either for long periods or
frequently.Note: Generally speaking, said conditions, when they occur, involve the
inside of tanks, pipes and containers, etc.
ZONE 21
Place where it is probable that an explosive atmosphere, in the form of a cloud of
combustible powders in the air, can occur occasionally during normal
operation.Note: Said zone can include, for example, among others, places in the
immediate vicinity of powder loading and emptying points and places where powder
layers form or which, during normal operation, could produce an explosive
concentration of combustible powders mixed with the air.
ZONE 22
Place where it is improbable that an explosive atmosphere, in the form of a cloud of
combustible powders in the air, occur during normal operation but which, if it does
occur, only persists for a short time.Note: This zone can comprise, among others,
places near appliances, protections systems and components containing powder,
out of which the powder can come out due to leaks with the formation of powder
deposits (e.g. milling salt, where the powder comes out of the mills and deposits).
ZONE 1
ZONE 2
ZONE O
ZONE 2O
ZONE 21
