- 5 -
If an extension cable is to be used, make sure that it is undamaged and
that it is the proper thickness for the length.
Cable length
h
Cable size
110V
230V
AWG
Normalization size
Up to 10 m
16
1.0 mm2²
Up to 15 m
14
1.25 mm2²
Up to 30 m
10
1.5 mm2²
Warm-up
In cold weather , warm up unit for 30-60 seconds so that the hydraulic oil
reaches the proper viscosity. Pull trigger-switch to extend piston and
release when it has reached its full stroke, Repeat 15-20 times.
Stopper adjustment
The correct position during cutting must be properly set for each size of
rebar before making a cut.
1.Screw in stopper to provide sufficient clearance for rebar.
2.Insert rebar fully into U-shaped support. Make sure that rebar is resting
on the base of the stopper.
3.Keeping rebar at right angels (90°) to front cutter block, screw out
stopper until it is just touching the rebar. Once set, the stooper needs no
further adjustment while cutting rebar of the same diameter, but must be
re-set for a different size rebar.
Caution: Failure to correctly set the stopper will result in excessive wear of
cutter block and may cause cut end to fly out.
Cutting
1.Insert rebar between stopper and front cutter block, making sure that it is
properly seated in U-shaped support.
2.Pull trigger -switch and keep depressed while piston advances and rebar
is cut. ( If switch is released at an intermediate point, piston will stop.)
3.When cut is completed, release switch. Piston retracts automatically.
(Note that switch can't be re-activated until piston has fully retracted.)
