2. Fiber strands installation on ceilings
With end fittings
Fiber tail ends can be mounted with
end fittings to present more optical
effects.
- 7 -
V. Fiber Bundle Assembly and Installation
1. Fiber connectors / couplings Assembly
Loosen the screws on the light
engine port ferrule, and insert
the ready fiber connector into
the ferrule. Then tighten the
screws against countersunk
holes on the fiber connector.
LED Light engine
1. Drill holes on the ceiling as
required by the pattern. Insert
the fiber strands into the holes
and glue them with the resin
adhesive. Cut the fiber ends
flush with the ceiling or leave
2-3mm protrusion
2. The fiber strands cannot be
folded in half, and the bending
radius should not be less than
10mm.
Fiber bundle
