Technical parameter
Drum dredge machine
Pipe diameter According to the choice of cable, the pipe size is also different, see
the table below).
Steel cable size
caliber
Pipe length
in.
ft.
（
M
）
3/8″（10mm）
2
—
4
50（15M）-100（30M）
1/2″（12mm）
2— 4
50（15M）-100（30M）
3/10
″
2
—
4
50
（
15M
）
Drum capacity
Standard Steel Rope Drum Six types of springs: 3/10 "X50 feet, 3/8" X50 feet, 75,
100 feet, and 1/2 "X50 feet, 75, and 100 feet
Rope drum speed 216/178RPM (unloaded)
Motor:
Type: 115V/60Hz, 230V/50Hz, reversible universal split phase AC motor.
Motor speed 1700r/min/1400r/min
Output power 180W/250W/370W/550W.
standard configuration
All drum dredging machines are equipped with a pair of dredging machine gloves
and two manual plastic dredging strips (used alone for simple blockage).
The drum dredging machine can be used to dredge the pipe of the corresponding
size. If the design, construction and installation of the pipeline are free, and the
blockage is not very serious, then it is effective to work and will not damage the
machine. It is suggested to use the pipe endoscope to understand the blockage
inside the pipeline before dredging, and then use the dredging machine to dredge.
The dredge machine cannot dredge all the blockage.
Machine assembly and special tips
Install wheels (with 4 wheels)
