Operator’s Manual Rev. 6/11/25 WL-100 MANUAL 06-25.DOCX
Table of Contents Copyright 2023, Vestil Manufacturing Corp. Page 19 of 30
WL-100-10-612
147.5
17 ¼”
74”
74”
14 ¼”
23 ¼”
111”
52”
20 ½”
16”
WL-100-10-712
147.5
17 ¼”
86”
74”
14 ¼”
29 ¼”
111”
52”
20 ½”
16”
WL-100-10-812
147.5
17 ¼”
98”
74”
14 ¼”
24”
111”
76
7
/
16
”
20 ½”
16”
WL-100-12-68
99 ½”
17 ¼”
74”
74”
14 ¼”
23 ¼”
87”
52”
5”
16”
WL-100-12-78
99 ½”
17 ¼”
86”
74”
14 ¼”
29 ¼”
87”
52”
5”
16”
WL-100-12-88
99 ½”
17 ¼”
98”
74”
14 ¼”
24”
87”
76
7
/
16
”
5”
16”
WL-100-12-610
123.5
17 ¼”
74”
74”
14 ¼”
23 ¼”
111”
52”
20 ½”
16”
WL-100-12-710
123.5
17 ¼”
86”
74”
14 ¼”
29 ¼”
111”
52”
20 ½”
16”
WL-100-12-810
123.5
17 ¼”
98”
74”
14 ¼”
24”
111”
76
7
/
16
”
20 ½”
16”
WL-100-12-612
147.5
17 ¼”
74”
74”
14 ¼”
23 ¼”
111”
52”
20 ½”
16”
WL-100-12-712
147.5
17 ¼”
86”
74”
14 ¼”
29 ¼”
111”
52”
20 ½”
16”
WL-100-12-812
147.5
17 ¼”
98”
74”
14 ¼”
24”
111”
76
7
/
16
”
20 ½”
16”
Notes:
1
Dimension is +0/-1”.
2
With Aluminum Bridge option (AL-ADDSATB), add 5” to L1 dimension, 2 ¼” to L2 dimension.
3
Preferred drain region indicates where the Lift’s base structure will not cover the drain. Install pit drains to suit local codes
and weather conditions.
Installation.
1. For pit installations, verify that the pit conforms to the pit diagram.
2. Place the power unit in the desired location. The standard 8-foot hose allows the power unit to be mounted
adjacent to the Dock Lift.
3. For pit installations, feed the required electric and hydraulic lines through the conduit.
4. Remove the cover from the power unit.
5. Have a qualified electrician connect the end-user’s power supply to the power unit’s motor relay (M1 on the
Electrical Diagram, p. 14). Verify that the supply voltage matches that listed on the Dock Lift data plate (located
on the right side of the platform). Verify that the control transformer (1T) primary lead wiring corresponds to
the supply voltage.
6. Remove all steel strapping and shipping materials from the Lift. Remove the lag screws holding the Lift to its
shipping pallet. Leave the eyebolts protruding through the deck in place.
7. Use rigging to lift the Dock Lift by the eyebolts. Move the Lift into position.
a. For pit installations, connect the hydraulic hose from the conduit to the quick-connect fitting on the
Lift’s frame before fully lowering the Lift into the pit. Take care to avoid damaging the hose or electrical
wires coming from the conduit.
b. For floor installations, the hydraulic hose may be connected after positioning the Lift.
8. REMOVE THE EYEBOLTS PROTRUDING THROUGH THE PLATFORM. The eyebolts will prevent the Lift from
operating.
9. Install the handrails on the platform.
10. Open the accessory bag.
a. Remove one handle-chain-snap link subassembly from the accessory bag. Attach one snap link to the
cold shut link on the handrail above the bridge; attach the other snap link to the hole in the bridge side
rail. Repeat for the second handle-chain-snap link subassembly.
b. Attach one loose quick link to the end of the loose chain. Hang the chain across one end of the
handrails. Repeat for the other end of the platform.
c. Connect the pendant control cord to the plug on the power unit.
11. Open the electrical enclosure. Install a jumper wire from terminal #3 to terminal #4 (1 TB).
