Table of Contents 2/19/2019 TT MANUAL
Table of Contents Copyright 2017 Vestil Manufacturing Corp. Page 2 of 13
Parts and Specifications:
Dimensions and other specifications for each TT-series turntable appear in the diagrams and tables on pages 2-6.
TT-8-4
Uniform capacity = 500 lb.
Turntable diameter = 8”
Base diameter = 6
1
/
8
”
Overall height = 3
15
/
16
”
Top plate thickness =
5
/
16
”
Net weight = 7.1 lb.
Rubber cover on top plate.
Bolt (4) must seat into groove on base post.
Groove in base
post
Item
Part no. Description Qty.
1
20-514-113
Weldment, frame, base
1
2 20-513-104 Weldment, top plate 1
3 99-110-006 Bearing ball,
3
/
8
” 1
4 38614
Metric hex bolt, class
8.8, z-finish, M8-
1.25x16mm
1
5
20-024-010
Guard, cover, mat
1
TT-8-7/8
Item
Part no.
Description
Qty.
1 20-110-011 Bearing ball carousel 1
2
20-013-018
Turntable platform plate
1
3 38561
Bolt, HHCS, class 8.8, z-
finish, M6-1.0x8mm
4
4 20-024-010 Guard, cover, mat 1
Uniform capacity = 500 lb.
Turntable diameter = 8”
Overall height =
3
/
4
”
Top plate thickness =
5
/
16
”
Net weight = 4.9 lb.
Rubber cover on top plate.
TT-12-7/8
Item
Part no.
Description
Qty.
1 20-110-007
Bearing ball carousel 1
2 20-013-017
Turntable platform plate 1
3 38561
Bolt, HHCS, class 8.8, z-
finish, M6-1.0x8mm
4
4 20-024-011
Guard, cover, mat 1
Uniform capacity = 500 lb.
Turntable diameter = 12”
Overall height =
13
/
16
”
Top plate thickness =
5
/
16
”
Net weight = 12.3 lb.
Rubber cover on top plate.
