Table of Contents 2/19/2019 TT MANUAL
Table of Contents Copyright 2017 Vestil Manufacturing Corp. Page 10 of 13
SIGNAL WORDS:
This manual classifies personal injury risks and situations that could lead to property damage with SIGNAL
WORDS. A safety message appears with a signal word that describes an improper/dangerous use of the product.
The signal word indicates the seriousness of the injury that could result from the described use.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Identifies practices likely to result in product or property damage, such as operation that
might damage the product.
TT-N-30-PED
Item
Part no.
Description
Qty.
1 20-514-075
Weldment, base 1
2 20-513-063
Weldment, deck 1
3 20-001-136
23.6” carousel assembly 1
4 20-013-032
Carousel top plate, TT-30 1
5
99-025-001
Knob,
1
/
2
” thread diameter
1
6 14-037-005
Rubber stop crutch tip 3
7
37015
10-32 lock nut, zinc-plated
4
8 24214 Flat head socket cap screw, #10-32 x 1
1
/
4
” 4
9 39955
Flat socket cap screw, class 10.9, black oxide
finish, M6-1.0x25mm
4
10
20-024-013
Guard, cover, mat
1
Uniform capacity = 300 lb.
Turntable diameter = 30”
Raised height = 31
11
/
16
”
Lowered height = 20
11
/
16
”
Top plate thickness =
5
/
16
”
Net weight = 127.6 lb.
Rubber cover on top plate.
To adjust tabletop height, loosen
knob (turn counterclockwise),
position tabletop at desired level;
then retighten knob.
