Table of Contents Rev. 0225 SY MANUAL
Table of Contents Copyright 2025 Vestil Manufacturing Co. Page 9 of 12
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
18-514-167
18-514-168
18-514-169
18-514-173
18-514-174
18-514-175
Weldment, frame:
SY-167236-L
SY-168436-L
SY-169336-L
SY-207236-L
SY-208436-L
SY-209336-L
1
1
1
1
1
1
1
18-514-179
18-514-180
18-514-181
18-514-184
18-514-185
Weldment, frame:
SY-257236-L
SY-258436-L
SY-259336-L
SY-307236-L
SY-308436-L
1
1
1
1
1
2
18-516-008
Weldment, swing arm mount
2
15
33625
Lock washer, medium split, plain,
1
/
2
”
20
3
16-132-288
Wheel, 18x3 mold-on rubber
wheel
2
16
12210
Hex bolt, gr. 5, plain finish,
1
/
2
”-13 x
1
3
/
4
”
16
4
18-516-004
Weldment, landing gear cylinder
mount
2
17
11207
Bolt, HHCS, #2, zinc plated,
1
/
2
”-13 x
1
1
/
4
”
2
5
33098
1
1
/
8
” SAE flat washer, z-plated
2
18
07-525-004
Assembly, handle
1
6
28-112-031
Clevis pin,
3
/
4
” x 4
1
/
2
”
2
19
07-025-005
Handle grip, black rubber, 6”
1
7
99-145-038
Chain,
3
/
8
” x 72”
2
20
18-514-242
Weldment, landing gear swing arm,
mold-on rubber
1
8
99-145-059
Chain hook,
5
/
16
”
2
21
99-021-936-
001
Cylinder, hydraulic, 1
1
/
2
” x 16”, ram
style
1
9
65080
Extended prong cotter pin, zinc
finish,
1
/
8
” x 2”
6
22
99-021-936-
001
Cylinder, hydraulic, 1
1
/
2
” x 16”, ram
style
1
10
29-001-103
Dock bumper, 5” x 16”
2
23
99-640-013
Assembly, hand pump,
1
/
2
gal. tank
1
11
33011
Flat washer, USS, plain,
1
/
2
”
42
24
33-112-034
Clevis pin, z-plated,
3
/
4
” x 3
3
/
4
”
2
12
13213
Hex bolt, gr. 5, zinc finish,
1
/
2
”-13 x
2
1
/
2
”
4
25
33-112-023
Clevis pin
2
13
12211
Hex bolt, gr. 5, plain,
1
/
2
”-13 x 2”
2
26
37147
1”-14 steel jam lock nut, nylon insert
2
14
36109
Hex nut, gr. A, plain finish,
1
/
2
”-13
18
27
18-001-309
Assembly, fork pocket for towing
1
EXPLODED VIEW AND BILL OF MATERIALS
SY-167236-L, SY168436-L, SY-169336-L, SY-207236-L,
SY-208436-L, SY-209336-L, SY-257236-L,
SY-258436-L, SY-259336-L, SY-307236-L,
AND SY-308436-L
18-006-272
