F:\Manual\SM-1517R-110V-100514 14.05.2010.
- 18 -
5-3 Status Indication
Follower-Plate Down
LS4-Down
LS3-Up
Power
For SM-2517 Only
Follower-Plate Up
Turntable Slow Down
Film Seat Zero Return
Turntable Zero Return
Film Cut
Stand By (AUTO)
○Power Pilot
When LED light is on, the power is at the “ON” status; when LED light is of f, the power is at the
“OFF” status.
○Stand By (AUTO)
The machine is in standby status.
○Film Seat Zero Return:
The film carrier is descending back to the Zero point.
○Turntable Zero Return:
The turntable is rotating back to the Zero point.
○Film Cut
The machine is breaking the film,
○Turntable Slow Down
The turntable is slowing down,
○Follower-Plate Up
The Follower-Plate is ascending,
○LS3-Up
LS3 is the (Zero point) lim it switc h: If this light on indicates the “Follower-Plate” has ascended
back to the Zero Point. If the “Follower-Plate” ha s not back to the Zero Point the m achine will not
be operated.
