F:\Manual\SM-1517R-110V-100514 14.05.2010.
- 14 -
5-1 Description of Key pad’s function on the control panel
No. of Upper Layers Counted:
Displays the num ber of com pleted upper layer wra pping cycles. Screen should be blank prior to
start of wrapping cycle. W hen wrapping cycle begins, for each com pleted upper layer wrapping
cycle the num ber increases by 1. W hen num ber of upper layers counted reaches the num ber of
upper layers set, the film-seat will start descending.
No. of Upper Layers Set:
Displays the number of wrapping cycles set for the upper layer.
Cycle Setting of Upper Layer:
Sets the number of upper layer wrapping cycles. Press “▲” once increases wrapping cycle by 1 and
press “▼” decreases wrapping cycle by 1. W rapping cycle can be set to 9 as m aximum, however
usually is set between 2-5 depending on dif ferent needs. Please note that wrapping cycle can not be
set to 0, as to lengthen the life span of the elevation motor.
No. of Lower Layers Counted:
Displays the num ber of com pleted lower layer wr apping cycles. Screen should be blank prior to
start of wrapping cycle. W hen wrapping cycle begins, for each com pleted lower layer wrapping
cycle the num ber increases by 1. W hen num ber of lower layers counted reaches the num ber of
lower layers set, the film-seat will start ascending.
No. of Lower Layers Set:
Displays the number of wrapping cycles set for the lower layer.
Cycle Setting of Lower Layer:
Sets the number of lower layer wrapping cycles. Press “▲” once increases wrapping cycle by 1 and
press “▼” decreases wrapping cycle by 1. W rapping cycle can be set to 9 as m aximum, however
usually is set between 2-5 depending on different needs.
Status Indication:
For detail, refer section 5-3.
Breakdown Indication:
For detail, refer section 5-4.
Wrapping Function Control:
For detail, refer section 5-2.
