Rev.9/29/2017 SPG,MANUAL
Copyright2017VestilManufacturingCo. Page3of6
F
ollowthestepsoutlinedbelow
t
oassembleyourSPG
‐
seriesgate
.L
ettersinpa
rentheses()correspondtoparts
identifiedinthediagramsonp.1.
1) Attachmountingbracketstotheguardrail.
a. Positionbothofthemountingbrackets(A)sothatthebottomboltholeisjustabovethemidrail;then
b. Inserta
1
/
2
in.‐13x3in.shoulderbolt(B)throughthetopboltholeinthebrackets;
c. Insertanothershoulderboltthroughthebottomholeinthebrackets{NOTE:Theboltwillcontactthe
topofthemidrail];andthen
d. Secureeachboltwitha
1
/
2
in.‐13hexnut(C).
2) FastenthegatesubassemblytothemountingbracketsasshowninFIG.1.
a. Aligntheboltholesinthegatesubassembly(D)withthe2middleholesinoneofthemountingbrackets
(A).
b. Puta
1
/
2
in.flatwasherontotwo
1
/
2
in.‐13x1
1
/
4
in.bolts;then
c. Inserttheboltsthroughthemountingbracketandsubassemblyandsecurethemwith
1
/
2
in.flatwashers
and
1
/
2
in.‐13hexnuts.
3) Fastenthegatesubassembly(D)totheguardrailasshowninFIG.2.
a. Puta
7
/
16
in.USSflatwasheronbothendsofthe
5
/
16
in.‐18x2in.U‐bolt;then
b. FeedtheendsoftheU‐boltthroughtheslotinthegatesubassembly;and
c. SecuretheendsoftheU‐boltwith
5
/
16
in.flatwashers,
5
/
16
in.lockwashers,and
5
/
16
in.‐18hexnuts.
4) Attachthegateframe(E)tothegateattachmentbrackets(F).
[NOTE:SPG‐40modelsincludepartscalledextenderbrackets.]
a. Determinehowlongthegateneedstobe.IfyouhaveanSPG‐40seriesgate,determineifextender
bracketsareneeded.Ifbracketsare
notnecessary,skippartbbelow.
b. [SPG‐40modelsonly]Attachextenderbracketstotheattachmentbracketswith
5
/
16
in.–18UNC
x1in.and
5
/
16
in.–18hexnuts.
c. Fastenthegateframetothelengthattachmentbracketsusing
5
/
16
in.‐18x1in.boltsand
5
/
16
in.‐18hex
nuts.Toproperlystabilizethestructure,inserttheboltsthroughtheboltholesattheendsofthegate
frameandthroughtheboltholesattheendsofthelengthattachmentbrackets.
SPG‐40withextenderbrackets
Extend
er bracket
Attachment
bracket
Gateframe
5
/
16
in.
–
18UNCx1in.
bolt
5
/
16
in.–18hexnut
