Specification
SPECIFICATION
SL-63-AA/FF SL-118-AA/FF SL-137-AA
Capacity
2000 lbs. 2000 lbs. 2000 lbs.
Fork Lift Height
63” 118” 137”
Capacity
2000 lbs. @ 63” 1500 lbs (63”-118”)
b)1500 lbs. @ (63-118”)
c)1000 lbs. @ (118-137”)
Fork Dimension
FF
AA
42x5.9 p5-x2 3/8”
42x4 p5-x1 ¼”
42x5.9x2 3/8”
42x4 p5-x1 ¼”
None
42x4 p5-x1 ¼”
Overall Fork Width
26 ¾” 26 ¾” 26 ¾”
Ground Clearance
1” 1” 1”
Lowered Fork H.
FF
AA
3 ¼”
2 1/8”
3 ¼”
2 1/8”
None
2 1/8”
H. Overall Extended
81 7/8” 140” 159”
Head Dimension
29 1/8x19 5/8x37” 29 1/8x19 5/8x37” 29 1/8x19 5/8x37”
Loading Center
21” 21” 21”
Wheel Base
FF
AA
39 ¾”
40 ½”
39 ¾”
40 ½”
None
40 ½”
Turning Radius
51” 51” 51”
Steering Wheel
Φ7x2” Φ7x2” Φ7x2”
Front Wheel
FF
AA
Ø3x3 ¼”
Ø4x2.9”
Ø3x3 ¼”
Ø4x2.9”
None
Ø4x2.9”
Overall Size
FF
AA
67 5/16x29 1/8x81 7/8”
66 1/8x29 1/8x81 7/8”
67 5/16x29 1/8x81 7/8”
66 1/8x29 1/8x81 7/8”
None
66 1/8x29 1/8x877/8”
Load
2.74”/s 2.95”/s 3.18”/s
Lift
Speed
Unload
4.84”/s 4.72”/s 4.41”/s
Load
(1 spd.)
2.42”/s 2.45”/s 2.3”/s
Load
(2 spd.)
4.5”/s 4.53”/s 5.4”/s
Unload (1
spd.)
2.42”/s 2.45”/s 2.3”/s
Lower
Speed
Unload (2
spd.)
4.2”/s 4.21”/s 5.4”/s
Lift Motor
12V/1.5KW 12V/1.5KW 12V/1.5KW
Amperage (Loaded)
165 amps. 165 amps. 177 amps.
Amperage (Unloaded)
65 amps. 105 amps. 107 amps.
Battery
12V/140Ah 12V/140Ah 12V/140Ah
Battery Charger
12VDC/5A 12VDC/5A 12VDC/5A
Weight
FF
AA
830 lbs.
870 lbs.
1020 lbs.
1070 lbs.
None
1140 lbs.
Width of Aisle
72” 72” 72”
FF: FIXED FORKS OVER SUPPORT LEGS
AA: ADJUSTABLE FORKS OVER ADJUSTABLE LEGS
Note: The load capacity is based on the situation when the center of the gravity is located at the center of length of
forks. When the center of gravity of goods is out of the center of forks, the load capacity will be lessened
compared to the center.
Copy
right 2025 Vestil Manufacturing Company
Page 5 of 35
SL, MANUAL
