Rev. 3/26/2014 SCTAB, manual.doc
Copyright 2014 Vestil Manufacturing Co.
Page 9 of 14
Auto-Shifter Foot Pump Bill of Materials:
Item
no. Part No. Description Quantity
1 99-039-001 Pump body, 1.25/0.75 bore 1
2 99-041-001 Piston, 1.25 x 0.75 1
3 99-041-002 Unloader piston 1
4 0.25 ball Chrome ball,
1
/
4
in., hardened 3
5 0.375 ball Chrome ball,
3
/
8
in., hardened 3
6 99-153-038 Flow control valve, pressure compensated, 1gpm 1
7 99-114-001 Beveled spring washer 8
8 99-146-008 Spring, relief 1
9 6409-06 SAE #6 port plug 3
10 6409-04 SAE #4 port plug 2
*11
BY-082306-1 Release seal retainer assembly
1
12 99-112-009 Release pin 1
13 99-016-018 Bracket, pivot plate 1
*14
0808-MRP
1
/
2
in. inner diameter x
1
/
2
in. outer diameter sleeve bearing
2
15 99-112-008 Pivot pin 1
16 CYR-1-S Cam bearing, 1in. outer diameter x
3
/
4
in. wide 1
*17
D-01250
Wiper, 1.25in. inner diameter x 1.5 outer diameter x
0.1875 high
1
*18
P-1250-1250 Seal 1.25 inner diameter x 0.125 cs
1
*19
RU-12500750-125 U-cup, 0.75in. inner diameter x 0.125 cs
1
20 33622
3
/
8
in. lock washer 3
21 33620
5
/
16
in. lock washer 1
22 25547
3
/
8
in. – 16 x 2in. socket head set screw 2
23 11057
5
/
16
in. x 1
1
/
4
in. hex headed bolt 1
24 11105
3
/
8
in. – 16 x 1
1
/
4
in. 1
25 99040-001 Release pedal/lever 1
26 64133
3
/
16
in. x 1in. spring pin 1
27 99-016-017 Bracket, pedal link 1
28 99-040-002 Lever, foot pedal, 2-speed auto-shifter 1
29 Pin
3
/
8
in. x 1
1
/
8
in. pin 1
30 99-146-004 Spring, inlet check 2
31 99-146-006 Spring, retainer, inlet check 2
32 99-146-005 Spring, outlet check 2
33 99-146-009 Spring, relief 1
34 99-146-007 Spring, release-ball 1
*35
OR-009-N70
O-ring,
7
/
32
in. inner diameter x
11
/
32
in. outer diameter x
1
/
16
in.
1
36 BY042806-1 Spring guide 1
37 BY042706-2 Relief valve body 1
38 304-C-06 Cap, #6 JIC 1
39 25537
3
/
8
in. – 16 set screw 2
40 36106
3
/
8
in. – 16 nut 2
*Foot pump seal kit 99-136-013 is comprised of Items 11, 14, 17-19, & 35
