Table of Contents Rev. 6/14/2024 SBM MANUAL
Table of Contents Copyright 2017 Vestil Manufacturing Co. Page 10 of 15
NATIONAL STANDARDS
This product is a “Below-the-Hook Lifting Device” (BTH lifter). ASME standard B30.20 (the
“Standard”) applies to BTH lifters. Acquire a copy of the latest version of the Standard before
putting the lifter into service. Follow all use and maintenance/care instructions provided in the
Standard as well as all other provisions for owners and users. If content in these instructions
conflicts with any recommendation or mandatory provision in the Standard, apply the
provision from the Standard. Vestil encourages you to immediately contact TECHNICAL
SERVICE if you discover any conflicts.
RECORD OF SATISFACTORY CONDITION
Record the condition of your lifting beam before putting it into service.
Economy models: Refer to diagrams on p. 11 as well as appropriate Exploded view
Measure the length and width of the bale. Record your measurements. Measure the throat
opening of each hook. Record your measurements. Examine both (hook) clevis pins and
shackle pins. Photograph all pins.
Adjustable Models: Refer to diagrams on p. 12 as well as appropriate Exploded View.
Disconnect the Beam Bale and Load Bales. Measure the length and width of the Beam
Bale. Measure the lengths and widths of the load bales. Record all measurements. Photograph
all 3 bales so that all features are clearly imaged.
All Models
Thoroughly photograph the spreader beam from multiple angles. Collect all photographs
and writings into a single file or computer folder. Mark the file appropriately to identify it. This
file/folder is a record of the lifting beam in satisfactory condition. Compare the results of all
inspections to this record to determine whether the unit is still in satisfactory condition. If the
lifter is not in satisfactory condition, repair it before returning it to service. Purely cosmetic
changes, like damaged paint/powdercoat, do not constitute changes from satisfactory
condition. However, touchup paint should be applied to all affected areas as soon as
cosmetic damage occurs to prevent rust/corrosion from accumulating. If left unaddressed,
rust/corrosion will eventually degrade the lifter from satisfactory condition and could make it
unsafe to use.
LOAD TESTS
After creating a RECORD OF SATISFACTORY CONDITION and before using the lifter for the
first time, a qualified person should conduct a load test. The test load should be 125% of the
rated load of the lifter. The rated load of all Economy SBM-series lifters is 800 pounds (363.6kg),
so the test load should be 1000 pounds (454.5kg). Adjustable SBM models have varying
capacities: Raise the lifter until it is suspended. Return the lifter to the ground and unload it.
Perform a Monthly Inspection as described in INSPECTIONS & MAINTENANCE (p.13). The lifter
must undergo load testing immediately after it is repaired, modified, or altered.
SPECIFICATIONS
Dimensions, net weight, and capacity information for each spreader beam model is provided
in the “Specifications” sections on pages 3, 4, 5, and 6. Specifications documents for SBM-series
spreader beams are available online to anyone who visits the Vestil website. Acquire the
appropriate specifications document by opening this webpage:
https://www.vestil.com/product.php?FID=571. Scroll down the page and click on the Download
Drawing icon ( ) to access the specifications drawing for your particular model.
