TABLE OF CONTENTS 5/13/2022 RR MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Page 8 of 11
7) For Models with the ES Option: If the trailer floor is below the dock’s floor, the Emergency Stop’s safety
legs need to be retracted. Pull the ES ring, the rear-most ring on the Dock Leveler, to retract the safety legs
and completely lower the lip onto the trailer’s floor. Release the ES ring.
8) Load / unload the cargo.
After use
If the truck departs before the dock leveler is retracted, the lip will fall to the down
position. The lip might not be in the keepers.
1) Pull the recessed handle, releasing the deck, until the lip clears the truck.
2) After the deck completely retracts, walk on the deck until it returns to floor height.
3) Verify the lip is behind the keepers.
4) The trailer’s overhead door and/or the building may now be closed and the wheel chocks removed.
Record of Satisfactory Condition
Before putting the dock leveler into service, make a record of its appearance and operations.
Photograph the unit from multiple vantage points in the lowered and fully elevated and extended
configurations. Take close range photographs of all labeling and information tags applied to the
machine. Photograph the deck, the lip, supporting frame, side/foot guards, and anchoring fasteners
(anchor bolts, etc.). Describe the motion of the deck as it elevates and descends, e.g. smoothly and
evenly from side-to side without binding or lurching. Describe the sound of the machine as it operates.
Collect all photographs and writings in a file. Mark the file appropriately to identify it. This file is a record of
the unit in satisfactory condition. Compare the results of all inspections to this RECORD to determine
whether the leveler is in satisfactory condition. Do not use the leveler unless it is in satisfactory condition.
Purely cosmetic changes, like damaged paint or powdercoat, are not changes from satisfactory
condition. However, touchup paint should be applied as soon as damage occurs.
Inspections & Maintenance
Any debris in, around, or under the Dock Leveler may impede
its actuation. In some
cases, an operator and/or equipment on top of the Dock Leveler may sl
ide off and fall
outside onto the ground causing damage and/or serious injury.
Before beginning maintenance, secure the deck in the raised configuration with the maintenance prop.
The process requires 2 people: one person presses and holds the RAISE button to keep the deck raised
with the lip extended, while the second person pivots the maintenance prop to align the free end of the
prop with the socket on the underside of the deck.
Every Use
• Inspect the Dock Leveler operation.
• Clear debris. Debris can be found between the Dock Leveler and the pit walls.
Monthly
• Verify labels are present, legible and securely attached. Request replacements from vendor as
necessary.
• Remove all debris from the pit. Clean the lip hinge and the lip operating mechanism. Wipe dirt and
material from the ratchet mechanism including the ratchet and paw. Clean the deck hinge.
• Inspect pull chain(s). They should pull without obstruction. The chain should not have excessive wear.
Replace as necessary.
• Use a graphite-based oil to liberally lubricate all moving parts. Include the hooking point at the end of
the springs. The only exception is the ratchet bar and the locking paw which should not be oiled.
• Grease the following zerk fittings with a lithium based grease:
o Lip hinge
o Pillow block at ends of trunnion
o Rotating cam in center of Dock Leveler deck
o If unit is equipped with safety stops grease both sides
• Inspect the springs.
