RR-Series & EH-Series Dock Levelers
Instruction Manual
RR Series (Mechanical)
EH Series (Electric-Hydraulic)
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading. If
the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance comply with
laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm
.
TABLE OF CONTENTS
Signal Words………………………………………………………………………………………………………….……………. 2
Hazards of Improper Use…………………………………………………………………………………………...…………….. 2
EH-65, EH-66, EH-68 and EH-610 Exploded View & Bill of Materials……………………………………………………….. 3
EH-75, EH-76, EH-78 and EH-710 Exploded View & Bill of Materials……………………………………………………….. 4
Power Unit Exploded View and Bill of Materials [EH-65; EH-66; & EH-68]………………………………………………….. 5
Power Unit Exploded View and Bill of Materials [EH-610; EH-75; EH-76; EH-78; & EH-710]…………………………….. 6
Manifold Exploded View and Bill of Materials [EH-65; EH-66; & EH-68]…………………………………………………….. 7
Manifold Exploded View and Bill of Materials [EH-610; EH-75; EH-76; EH-78; & EH-710]……………………………….. 7
Electrical Circuit Diagram, 115V AC, 1-Phase [EH Dock Levelers]..……………………………………..………………….. 8
Electrical Circuit Diagram, 208-230V AC, 1-Phase [EH Dock Levelers]……...……………………………………………… 9
Electrical Circuit Diagram, 3-Phase AC [EH Dock Levelers]………………………………………………………………….10
Electrical System Operation [EH Dock Levelers]..……………………………………………………………...…………….. 11
Hydraulic Circuit Sequence of Operation [EH Dock Levelers]……………………………………………………………….. 11
Adjusting Hydraulic Settings [EH Dock Levelers]…………………………………………………………………….............. 12
RR-65, RR-66, RR-68, and RR-610 Exploded View and Bill of Materials…………………………….………………. 13 - 14
RR-75, RR-76, RR-78, and RR-710 Exploded View and Bill of Materials…………………………………………….. 15 - 16
Installation…………………………………………………………………………………………………………………………. 17
Operation: EH Series………………..…………………………………………………………………………………....17, 18, 19
Operation: RR Series…………………………………………………………………………………………………………….. 19
Troubleshooting: EH-Series…………………...…………………………………………………………………………........... 20
Inspections and Maintenance: EH-Series………………………………...……………………………………………………. 21
Inspections and Maintenance, RR-Series………………………………………………………………………………........... 22
Adjusting Spring Tension: RR-Series…………………………………………………………………………………………… 23
Labeling Diagrams: RR-Series and EH-Series………..………………………………………………………………………. 24
Limited Warranty………………………………………………………………………………………………………………….. 25
