Rev.7/17/2018RDC‐100,MANUAL
Copyright2017VestilManufacturingCorp. Page8of9
InspectionsandMaintenance:
Beforeusingthecartforthefirsttime,createawrittenrecordofitsappearanceandfunctions.Includedetailed
descriptions about the frame, casters, wheels, rollers, and handle. Lift a drum with the cart by following the
instructionsin“Usingthecart”onp.7.Recordobservationsabouthowthecartrespondswhenweightisappliedto
it.Thoroughlyphotographtheunitincludingalllabelsappliedtoit.Addthe
photographstoyourrecord.Thiswritten
record establishes “normal condition”. When conducting future inspections, compare your observations with the
recordtodetermineifacomponentisinnormalconditionorrequiresrepairorreplacement.
Regularinspectionsandmaintenancearenecessarytokeepthecartinnormalcondition foraslong
aspossible.
Do not use the cart unless it is in normal condition. Complete all necessary replacements and repairs before
returningthecarttoservice.
Step1:Tagthecart“OutofService.”
Step2:Atleastoncepermonth,inspecttheelementslistedbelow.[Referto“PartsDiagrams”onp.3,4.]
a)
Frame: Inspect all welds for cracks. Inspect the metal tubing for damage, warps, and cracks. Payparticular
attention to areaswhere thewheels, rollers,and castersfasten to the frame. Make sure that all hardware is
securelyfastenedtogetherandthattheboltholesintheframearenotelongated,warped,orcracked.
b)
Casters, wheels, and rollers: Check each of the items for excessive wear, cracks, etc. Both casters and both
wheels shouldsolidlycontactthegroundandshould roll smoothlywithoutwobbling. Examine the center
hub of each casterforcracks.Examineall(8)ofthedrumrollers.
c)
Handleandhandlereceiver: Confirm that the handle is securely fastened to the receiver (bolt and wing
nut). Check the welds that fuse the receiverto the frame. Make sure that the receiver opening is not
elongated,cracked,etc.Examinethehandleforcracks,flattenedregions,andotherdamage.
Step3: Completeallnecessaryrepairs/replacements. Deformities,severe corrosionorrusting, or excessive wear of
any part warrants immediate replacement of that part. DO NOT return the table to service until adjustmentsand
repairsarecomplete!NOTE:Adjustmentsandrepairsdiffersignificantlyfrommodifications:
a)
Adjustments&repairsaresimplecorrectionthatrestores thecarttonormaloperatingcondition. Examples
includetighteningloosefastenersandlubricatingmovingparts.
b)
Modificationsarechangesthatalterthecart fromoriginal condition,likebending theframe. NEVERmodify
the cartwithoutexpress,writtenapprovalfromVestil.Modificationsautomaticallyvoidthelimitedwarranty
andmight makethedeviceunsafetouse.
Step4: Makeadatedrecordofallrepairs,adjustmentsandreplacements.
Step5:Storethecartindoorsinadrylocation.
LabelingDiagram:
Thetableshouldalwaysbelabeledasshowninthisdiagram.However,labelcontentandlocationaresubject
tochangesoyourproductmightnotbelabeledexactlyasshown.Thoroughlyphotographtheunitwhenyou
firstreceiveitasdiscussedinthe“WrittenRecord”portionoftheInspectionsandMaintenance
section(above).
Makesurethatyourrecordincludesaphotographofeachlabel.Replacealllabelsthatare,orlaterbecome,
damaged,missing,ornoteasilyreadable(e.g.faded).OrderreplacementlabelsbycontactingtheTechnical
Service&Partsdepartmentonlineathttp://www.vestilmfg.com/parts_info.htmorbycalling(260)665‐7586and
askingtheoperatortoconnectyoutothePartsDepartment.
A
B
A: Label 287
B: Label 658
