Table of Contents Rev. 10/28/2020 PEL MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 6 of 17
FIG. 2: PEL-88-A and PEL-100A exploded view and bill of materials
Item
Part no.
Description
Qty.
Item
Part no.
Description
Qty.
1
42-514-002
42-514-003
Weldment, frame:
PEL-88A
PEL-100A
1
1
17 21-156-006
Accessory, electrical control box 1
2
42-525-001
Weldment, handle
1
18
21-024-042
Cover, motor
1
3 42-513-002 Weldment, deck 1 19
21-641-008
21-641-009
Screw drive:
PEL-88A: 64
5
/
8
” length
PEL-100A: 75
3
/
8
” length
1
1
4
21-013-057
Deck, top
1
20
21-034-025
Flanged inlet sleeve with locking ring
1
5
42-538-001
Weldment, carriage
1 21
11012
Hex bolt, gr. A, zinc finish,
1
/
4
”-
20x2
1
/
4
”
4
6
16-132-163
Caster with brake, PP-3/1.25-STM-
TTL
2 22
21-034-004
Circuit breaker
1
7
16-132-164
Caster, swivel, PP-3/1.25-STM
2
23
42-111-001
Bearing, sleeve
1
8
37024
Nylon insert lock nut, grade 2,zinc
finish,
3
/
8
”-16
4 24 42-024-002
Cover/guard, top cap 1
9
42-110-001
Bearing, roller
4
25
33618
Medium split lock washer,
1/
4
”
2
10
24213
Flat head socket cap screw #10-32x1”
6
26
33004
Flat washer, USS, zinc-plated,
1/
4
”
2
11
37015
10-32 lock nut, zinc plated
4
27
33006
Flat washer, USS, zinc plated,
5/
16
”
4
12
11105
Hex bolt, grade A, zinc plated,
3
/
8
”- 16
x 1”
4 28
37018
Nylon lock nut, gr. 2, zinc finish
1/
4
” -
20
2
13
11003
Hex bolt, grade A, zinc plated,
1
/
4
”-20 x
3
/
4
”
4 29
64137
Spring pin, AISI 1070-1095, pain
finish,
3/
16
” x 1
1/
2
”
1
14
21-156-002
Control, touchpad, electronic
1
30
21-024-038
Handle, grip, flexible vinyl round cap
2
15
21-139-001
Battery, 12VDC
2
31
15-025-006
Grip, handle
2
16
21-034-010
Accessory, battery charged, 24V
1
32
42-027-002
Brush seal, standard PP flex
2
