Table of Contents Rev. 10/28/2020 PEL MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Corp. Page 8 of 17
Item
Part no.
Description
Quantity
1
21-002-059
21-002-060
Final assembly without power unit:
PEL-400-57
PEL-400-72
1
1
1.1
21-514-068
21-514-069
Frame, weldment:
PEL-400-57
PEL-400-72
1
1
1.2
21-516-009
Weldment, bracket, sprocket
1
1.3
10896
HHCS tap bolt
1
/
2
” – 13UNC x 6” fully threaded
1
1.4
21-146-005
Spring, compression
1
1.5
33012
Flat washer, low carbon, zinc finish,
1
/
2
”
1
1.6
36209
1
/
2
” – 13 hex jam nut, plain
3
1.7
21-113-033
Spacer, 23/32” length
2
1.8
26356
SHSCS,
1
/
2
” x 2
1
/
2
” shoulder,
3
/
8
” – 16 THD
2
1.9
37024
Nylon insert lock nut, grade 2, zinc finish
3
/
8
” – 16
4
1.10
21-113-032
Spacer,
9
/
16
” length
2
1.11
21-042-018
Sprocket, idler
6
1.12
26353
Socket head shoulder bolt,
1
/
2
” x 1
3
/
4
” with
1
/
4
” hex,
3
/
8
” – 16UNC threads
1
1.13
26358
3
/
8
” – 16 SHSB,
1
/
2
”x 3” shoulder
1
1.14
21-113-030
Spacer,
1
/
4
” length
2
1.15
16-132-342
Stem caster, welded, rigid
2
1.16
16-132-156
4” stem caster with brake
2
1.17
21-024-024
Cover, left side, formed
1
1.18
21-024-023
Cover, right side, formed
1
1.19
37032
1
/
2
” nylon insert jam nut
4
1.20
31802
Self-tapping screw
14
2
21-024-029
Guard, top, formed
1
3
15-025-006
Grip, handle
2
4
21-145-004
Bolt, chain, adjustment,
1
/
2
” – 13 x 2
1
/
4
”
4
5
36209
1
/
2
” – 13 hex jam nut, plain
8
6
11055
Hex bolt, grade A, zinc plated,
5
/
16
” – 18 x 1”
2
7
37021
Nylon insert lock nut, grade 2, zinc finish,
5
/
16
” – 18
2
8
21-139-002
Battery, 12V DC
2
9
15-016-068
Bracket, battery charger mount, formed
1
10
33004
Flat washer, USS zinc plated,
1
/
4
”
6
11
11003
Hex bolt, grade A, zinc plated,
1
/
4
” – 20 x
3
/
4
”
4
12
37018
Nylon lock nut, grade 2, zinc finish,
1
/
4
” – 20
3
13
21-034-010
Accessory, electric battery charger, 24V
1
14
21-156-004
Control, motor, electronic, 1228
1
15
27402
RHSMS #8-32 x 1” long
2
16
01-022-001
Limit switch with roller arm
1
17
22804
Flat countersunk head elevator bolt, plain finish,
1
/
4
” – 20 x 1
1
/
2
”
1
18
21-641-002
Leeson motor/gearbox
1
19
21-156-002
Control, touchpad, electronic
1
20
21-034-025
Flanged inlet sleeve with locking ring
1
21
21-034-004
Circuit breaker
1
22
21-042-019
Gearbox sprocket
1
23
11107
Hex bolt, grade A, zinc finish,
3
/
8
” – 16 x 1
1
/
4
”
4
24
37024
Nylon insert lock nut, grade 2, zinc finish,
3
/
8
” – 16
4
25
21-024-038
Handle, grip, flexible vinyl, round cap
2
26
99-034-013
Strap, battery box, with buckle
1
27
33618
Medium split lock washer,
1
/
4
”
2
28
21-042-017
21-042-021
Chain:
PEL-400-57: #40-1R x 265 links
PEL-400-72: #40-1R x 325 links
2
2
29
21-513-036
Subassembly, carriage with deck
1
29.1
21-538-037
Subassembly, carriage
1
29.1.1
21-538-036
Weldment, carriage
1
29.1.2
21-112-008
Pin, rollers
4
29.1.3
21-527-003
Assembly, roller bearing
4
29.1.4
64135
Pin, roll pin,
3
/
16
” x 1
1
/
4
”
4
29.2
21-513-090
Subassembly, deck
1
29.2.1
21-513-035
Weldment, deck
1
29.2.2
21-013-064
Deck, top
1
29.2.3
24213
Flat head socket cap screw #10-32 x 1” long
4
29.2.4
37015
10-32 Nylock nut, zinc-plated
4
29.3
33008
Flat washer, low carbon, USS, zinc plated,
3
/
8
”
8
29.4
11107
Hex bolt, grade A, zinc finish,
3
/
8
” – 16 x 1
1
/
4
”
4
29.5
33622
Split lock washer, carbon steel, medium zinc finish,
3
/
8
”
4
29.6
36106
Hex nut, grade A, zinc plated,
3
/
8
” – 16
4
30
21-037-020
Stop, rubber bumper
2
31
31807
Self-drilled screw, steel, zinc-plated, #8-18 x 1
1
/
4
”
4
FIG. 3 Bill of Material: PEL-400-57 and PEL-400-72
