Table of Contents Rev. 8/28/2024 LM MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Co. Page 9 of 25
FIG. 2F: LM-OBNT-4k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-132
08-514-302
08-514-303
Weldment, frame, boom + base
LM-OBNT-4-24
LM-OBNT-4-30
LM-OBNT-4-36
1
1
1
2
01-146-006
Spring
1
3
08-014-069-001
Frame, front support leg (small)
casting
1
4
08-145-001
Swivel hook, 2-ton
1
5
08-145-041
5
/
16
” snap hook
1
6
08-145-010
1
/
2
” 2-ton shackle
1
7
08-645-008
Assembly, boom chain and pin
1
8
13-025-023
1
1
/
8
” inner diameter red handle grip
1
9
99-145-084
Lap link
1
10
99-645-019
2-ton hook and shackle
1
11
11210
1
/
2
” – 13UNC x 1
3
/
4
” hex bolt
1
12
36110
1
/
2
” – 13 zinc-plated hex nut
1
FIG. 2G: LM-OBNT-6k Exploded View & Bill of Materials
FIG. 2H: LM-OBNT-8k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-134
08-514-304
08-514-305
Weldment, frame, boom + base
LM-OBNT-6-24
LM-OBNT-6-30
LM-OBNT-6-36
1
1
1
2
01-146-006
Spring
1
3
08-014-069-001
Frame, front support leg (small)
casting
1
4
08-145-001
Swivel hook, 2-ton
1
5
08-145-002
Swivel hook, 3-ton
1
6
08-145-041
5
/
16
” snap hook
1
7
08-145-010
1
/
2
” 2-ton shackle
1
8
08-645-008
Assembly, boom chain and pin
1
9
13-025-023
1
1
/
8
” inner diameter red handle grip
1
10
99-145-019
5
/
8
” 3
1
/
4
-ton shackle
1
11
99-145-084
Lap link
1
12
11210
1
/
2
” – 13UNC x 1
3
/
4
” hex bolt
1
13
36110
1
/
2
” – 13 zinc-plated hex nut
1
Item
Part No.
Description
Quantity
1
08-514-136
08-514-308
08-514-309
Weldment, frame, boom + base
LM-OBNT-8-24
LM-OBNT-8-30
LM-OBNT-8-36
1
1
1
2
01-146-006
Spring
2
3
08-014-069-001
Frame, front support leg (small)
casting
1
4
08-145-006
7
/
8
” 6
1
/
2
-ton shackle
1
5
08-145-002
Swivel hook, 3-ton
1
6
08-145-041
5
/
16
” snap hook
1
7
08-145-005
Swivel hook, 5-ton
1
8
08-645-008
Assembly, boom chain and pin
1
9
13-025-023
1
1
/
8
” inner diameter red handle
grip
1
10
99-145-019
5
/
8
” 3
1
/
4
-ton shackle
1
11
99-145-084
Lap link
1
12
11211
1
/
2
” – 13UNC x 2” hex bolt
1
13
36110
1
/
2
” – 13 zinc-plated hex nut
1
