Table of Contents Rev. 8/28/2024 LM MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Co. Page 7 of 25
FIG. 2A: LM-OBT-3-24 & LM-OBT-4k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-119
08-514-298
08-514-299
Weldment, frame, boom + base:
LM-OBT-4k-24 & LM-OBT-3-24
LM-OBT-4k-30
LM-OBT-4k-36
1
1
1
2
08-514-293
Weldment, inner tube
1
3
01-146-006
Spring
1
4
08-014-069-001
Frame, front supporting leg (small)
casting
1
5
08-145-001
Swivel hook, 2-ton
1
6
08-145-041
5
/
16
” snap hook
1
7
08-145-010
1
/
2
” 2-ton shackle
1
8
08-645-008
Boom chain and pin
1
9
13-025-023
1
1
/
8
” i.d. red handle grip
1
10
99-645-019
2-ton hook and shackle
1
11
99-145-084
Lap link
1
12
11210
1
/
2
” – 13UNC x 1
3
/
4
” hex bolt
1
13
36110
1
/
2
” – 13UNC zinc-plated hex nut
1
FIG. 2B: LM-OBT-6k Exploded View & Bill of Materials
FIG. 2C: LM-OBT-8k Exploded View & Bill of Materials (08-006-131)
Item
Part No.
Description
Quantity
1
08-514-122
08-514-300
08-514-301
Weldment, frame, boom + base:
LM-OBT-6k-24
LM-OBT-6k-30
LM-OBT-6k-36
1
1
1
2
08-514-293
Weldment, inner tube
1
3
01-146-006
Spring
1
4
08-014-069-001
Frame, front supporting leg (small)
casting
1
5
08-145-001
Swivel hook, 2-ton
1
6
08-145-002
Swivel hook, 3-ton
1
7
08-145-041
5
/
16
” snap hook
1
8
08-145-010
1
/
2
” 2-ton shackle
1
9
08-645-008
Boom chain and pin
1
10
13-025-023
1
1
/
8
” i.d. red handle grip
1
11
99-145-019
2-ton hook and shackle
1
12
99-145-084
Lap link
1
13
11210
1
/
2
” – 13UNC x 1
3
/
4
” hex bolt
1
14
36110
1
/
2
” – 13UNC zinc-plated hex nut
1
Item
Part No.
Description
Quantity
1
08-514-125
08-514-311
08-514-312
Weldment, frame, boom + base:
LM-OBT-8k-24
LM-OBT-8k-30
LM-OBT-8k-36
1
1
1
2
08-514-310
WELDMENT, INNER TUBE-8K
1
3
01-146-006
SPRING
2
4
08-014-069-
001
FRAME, FRONT SUPPORT LEG (SMALL)
CASTING
1
5
08-145-002
SPEC HDW, SWIVEL HOOK 3-TON
1
6
08-145-005
SPEC HDW, SWIVEL HOOK 5-TON
1
7
08-145-006
Ø 7/8 -6 1/2 TON SHACKLE
1
8
08-145-041
SNAP HOOK, Ø5/16
1
9
08-645-008
ASSEMBLY, BOOM CHAIN AND PIN
1
10
13-025-023
HANDLE, GRIP, 1 1/8" I.D., RED
1
11
99-145-019
SPECIALTY HARDWARE, SHACKLE
1
12
99-145-084
LAP LINK, 5/16" X 1 1/2"
1
13
11211
HEX BOLT, GR A, ZN FINISH, 1/2"-13 x 2"
1
14
37030
1/2"-13 NYLON INSERT LOCK NUT, GR 2
1
