Table of Contents Rev. 8/28/2024 LM MANUAL
Table of Contents Copyright 2020 Vestil Manufacturing Co. Page 5 of 25
FIG. 1F: LM-1NT-4k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-319
08-514-128
08-514-320
08-514-321
Weldment, frame, boom/base:
LM-1NT-4-11
LM-1NT-4-24
LM-1NT-4-30
LM-1NT-4-36
1
1
1
1
2
08-014-134
Frame, front support leg casting
1
3
08-145-001
Swivel hook, 2-ton
1
4
08-145-041
5
/
16
” snap hook
1
5
08-145-010
1
/
2
” 2-ton shackle
1
6
99-145-037
5
/
16
” chain 36” long
1
7
99-145-084
Lap link
1
8
99-645-019
2-ton hook and shackle
1
9
11211
1
/
2
in. – 13 UNC x 2in. HHCS zinc-
plated bolt
1
10
36109
1
/
2
in. – 13 UNC hex nut
1
FIG. 1G: LM-1NT-6k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-322
08-514-129
08-514-323
08-514-324
Weldment, frame, boom/base:
LM-1NT-6-11
LM-1NT-6-24
LM-1NT-6-30
LM-1NT-6-36
1
1
1
1
2
08-014-134
Frame, front support leg
casting
1
3
08-145-001
Swivel hook, 2-ton
1
4
08-145-002
Swivel hook, 3-ton
1
5
08-145-041
5
/
16
” snap hook
1
6
08-145-010
1
/
2
” 2-ton shackle
1
7
99-145-019
5
/
8
” 3.25-ton shackle
1
8
99-145-037
5
/
16
” chain 36” long
1
9
99-145-084
Lap link
1
10
11211
1
/
2
in. – 13 UNC x 2in. HHCS zinc-
plated bolt
1
11
36109
1
/
2
in. – 13 UNC hex nut
1
FIG. 1H: LM-1NT-8k Exploded View & Bill of Materials
Item
Part No.
Description
Quantity
1
08-514-130
08-514-317
08-514-318
Weldment, frame, boom/base:
LM-1NT-8-24
LM-1NT-8-30
LM-1NT-8-36
1
1
1
2
08-014-134
Frame, front support leg
casting
1
3
08-145-002
Swivel hook, 3-ton
1
4
08-145-005
Swivel hook, 5-ton
1
5
08-145-006
7
/
8
” 6.5-ton shackle
1
6
08-145-041
5
/
16
” snap hook
1
7
99-145-019
5
/
8
” 3.25-ton shackle
1
8
99-145-037
5
/
16
” chain 36” long
1
9
99-145-084
Lap link
1
10
11211
1
/
2
in. – 13 UNC x 2in. HHCS zinc-
plated bolt
1
11
36110
1
/
2
” – 13UNC zinc-plated hex
nut
1
